凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-54) - ADDITIONAL PARTS FOR WISCONSIN ENGINE, ENGINE BASE AND PULLEYS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
824 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
663482R1
|
[1] |
|
P
PULLEY, engine drive
|
| . . |
657205R1
|
[1] |
|
P
KEY, 3/8 x 3-1/4 sq parallel 3/8" Sq x 3 1/4", Par
|
| . . |
102597
|
[2] |
SET SCREW
|
IH
SCREW, 3/8-16 x 1 hex-soc-hd cup pt set Superseded by part number: 83-616
|
| 2. |
663190R1
|
[1] |
|
P
PULLEY, idler
|
| 3. |
86636814
|
[1] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
FITTING, 1/4-28 NF-2 str lub Superseded by part number: 88775
|
| 4. |
663294R91
|
[1] |
|
P
BRACKET ASSY, idler pivot
|
| 5. |
663374R1
|
[1] |
|
P
TRUNNION, idler pulley rod
|
| 6. |
663302R1
|
[1] |
|
P
SUPPORT, idler trunnion
|
| 7. |
663299R1
|
[1] |
|
P
PIVOT, idler
|
| . . |
615102R1
|
[2] |
WASHER
|
IH
9/16 x 1-5/8 x 22 ga Superseded by part number: 495-21056
|
| . . |
551660R1
|
[2] |
WASHER
|
CAS
1-5/32 x 2 x 16 ga Superseded by part number: 20885R1
|
| 8. |
663371R1
|
[2] |
|
P
ECCENTRIC, idler
|
| 9. |
663372R1
|
[2] |
|
P
SPACER, idler
|
| 10. |
663625R91
|
[2] |
BALL BEARING
|
CAS
ASSY, idler Superseded by part number: 84330089
|
| 11. |
663373R1
|
[1] |
|
P
SPACER, idler bearing
|
| 12. |
663300R1
|
[1] |
|
P
SUPPORT, engine base
|
| 13. |
663301R1
|
[1] |
|
P
BASE, engine
|
| 14. |
663375R1
|
[2] |
|
P
BRACE, fuel tank
|
| 15. |
663443R1
|
[1] |
|
P
BRACKET, fuel tank right
|
| 17. |
663444R1
|
[1] |
|
P
BRACKET, fuel tank left
|
| 18. |
663298R1
|
[1] |
|
P
BRACE, engine base
|
| . . |
27385D
|
[1] |
|
P
CLIP, fuel line
|
| . . |
52728D
|
[1] |
|
P
CUSHION, fuel line
|
