凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-53) - ADDITIONAL PARTS FOR C-123 ENGINE, ENGINE MOUNTS AND IDLER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
663276R91
|
[1] |
|
P
ROD ASSY, engine idler adjusting
|
| 3. |
663283R91
|
[1] |
|
P
ARM ASSY, engine idler
|
| . . |
661166R1
|
[1] |
|
P
BOLT, 3/8-16 x 2-1/2 special hex-hd mach
|
| . . |
Q1504
|
[2] |
WASHER
|
IH
13/32 x 7/8 x 16 ga Superseded by part number: 495-21044
|
| . . |
Q3479
|
[1] |
WASHER
|
IH
29/32 x 1-3/8 x 14 ga Superseded by part number: 495-81054
|
| 5. |
663368R1
|
[1] |
|
P
WASHER, engine idler arm pivot
|
| 6. |
663288R1
|
[1] |
|
P
PIVOT, engine idler arm
|
| . . |
114503
|
[1] |
JAM NUT,Jam, 3/8"-16, G5
|
IH
Superseded by part number: 329-146
|
| 7. |
663287R1
|
[1] |
|
P
BRACE, engine idler arm pivot
|
| 8. |
109461
|
[2] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 9. |
663280R91
|
[1] |
|
P
STRAP ASSY, engine idler arm hammer
|
| 10. |
B32368
|
[3] |
|
IH
WASHER, engine idler pulley
|
| 11. |
B32367
|
[2] |
|
IH
WASHER, engine idler pulley notched
|
| 12. |
451891R1
|
[1] |
|
P
RACE, engine idler bearing
|
| 13. |
11387P
|
[1] |
|
P
WASHER, engine idler end thrust
|
| 14. |
5174PA
|
[1] |
|
P
PULLEY, engine idler
|
| 15. |
656874R1
|
[1] |
|
P
GASKET, pulley cap
|
| 16. |
659371R91
|
[1] |
|
P
CAP ASSY, pulley
|
| 17. |
74036H
|
[2] |
BEARING
|
IH
ASSY, idler pulley Superseded by part number: 102024R91
|
| 18. |
11449P
|
[1] |
SPACER,1 1/4" Pipe x 1/2"
|
IH
engine idler pulley bearing
|
| 19. |
668689R1
|
[2] |
|
P
GUIDE, drive belt
|
| . . |
Q1505
|
[2] |
WASHER
|
IH
13/32 x 1 x 16 ga Superseded by part number: 495-21044
|
