沃尔沃零件查询MD2010A; MD2020A; MD2030A; MD2040A; MS2B-R; MS2A-D; MS2A-E; MS2L-D; MS2L-E; 120S-D; 120S-E; MD2010; MD2030; MD2040; MD2020Fuel SystemFuel SystemEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
318 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3580100
|
[1] |
Feed pump
|
|
| 1. |
|
|
|
|
| 2. |
3580111
|
[1] |
Gasket
|
|
| 3. |
3580269
|
[2] |
Screw
|
|
| 4. |
3580107
|
[1] |
Banjo nipple
|
|
| 5. |
3580395
|
[1] |
Tube
|
|
| 6. |
3580393
|
[1] |
Stay
|
|
| 7. |
3580104
|
[4] |
Screw
|
|
| 8. |
3580109
|
[2] |
Screw
|
|
| 9. |
3580108
|
[2] |
Washer
|
|
| 10. |
3580015
|
[2] |
Spring washer
|
|
| 11. |
971071
|
[2] |
Hexagon nut
|
|
| 12. |
3580095
|
[1] |
Fuel filter
|
|
| 13. |
861477
|
[1] |
Fuel filter
|
(3580096)
|
| 14. |
969011
|
[5] |
Gasket
|
|
| 15. |
837322
|
[1] |
Nipple
|
|
| 15A. |
11992
|
[1] |
Gasket
|
|
| 15B. |
471177
|
[1] |
Hollow screw
|
|
| 16. |
3580098
|
[1] |
Hollow screw
|
|
| 16A. |
3580690
|
[1] |
Hollow screw
|
|
| 17. |
3580394
|
[1] |
Rubber hose
|
|
| 18. |
961663
|
[2] |
Hose clamp
|
|
| 19. |
3580101
|
[1] |
Banjo nipple
|
|
| 20. |
3580382
|
[1] |
Injection pump
|
|
| 20. |
|
|
|
|
| 21. |
|
|
|
Included in fuel injection pump.
|
| 22. |
|
|
|
Included in fuel injection pump.
|
| 23. |
|
|
|
Included in fuel injection pump.
|
| 24. |
3580388
|
[1] |
Delivery pipe
|
Cyl no 1
|
| 25. |
3580389
|
[1] |
Delivery pipe
|
Cyl no 2
|
| 26. |
3580390
|
[1] |
Delivery pipe
|
Cyl no 3
|
| 27. |
3580082
|
[4] |
Clamp
|
|
| 28. |
3580083
|
[2] |
Screw
|
|
| 29. |
945407
|
[2] |
Flange nut
|
|
| 30. |
3580264
|
[1] |
Spacer
|
|
| 31. |
3580074
|
[2] |
Screw
|
|
| 32. |
|
|
|
Included in cylinder block.
|
| 33. |
945407
|
[2] |
Flange nut
|
|
| 34. |
3580386
|
[3] |
Injector
|
|
| 34. |
3803441
|
[3] |
Injector
|
|
| 34. |
|
|
|
|
| 35. |
|
|
|
Included in fuel injector.
|
| 36. |
3580385
|
[3] |
Nozzle sleeve
|
|
| 37. |
3580384
|
[3] |
Insert
|
|
| 38. |
3580383
|
[3] |
Gasket
|
|
| 39. |
|
|
|
Included in fuel injector.
|
| 40. |
|
|
|
Included in fuel injector.
|
| 41. |
3580387
|
[1] |
Tube
|
|
| 42. |
11991
|
[2] |
Gasket
|
|
| 43. |
3580094
|
[1] |
Screw
|
|
