凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-56[A]) - BALE CHUTE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
179 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
669647R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN ASSY, bale chute holdup
|
| 1. |
662325R91
|
[2] |
CHAIN (AG)
|
IH
CHAIN ASSY, bale chute holdup, used with 24-1/2 in. bale chute only
|
| . . |
668986R1
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 short sq-nk crg Superseded by part number: 280827
|
| . . |
657803R1
|
[2] |
|
P
NUT, 5/16-18 wing
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| 2. |
668682R2
|
[1] |
|
P
CHUTE, bale
|
| . . |
575807R1
|
[2] |
WASHER
|
IH
13/32 x 1 x 11 ga Superseded by part number: 95-81086
|
