凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-57) - ENGINE SHUT-OFF ATTACHMENT, FIBER BAR TYPE, FOR WIRE BALER, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
548 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
Q530
|
[1] |
HEADED PIN,7.92mm OD x 63.5mm L
|
IH
PIN, 5/16 x 2-1/2 std-hd
|
| . . |
103384
|
[1] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 2. |
659235R1
|
[1] |
|
P
ACTUATOR, engine shutoff
|
| . . |
490-1108
|
[1] |
SCREW,Cross Pan Hd, #10-32 x 1/2"
|
CAS
10-32 x 1/2 cd-pltd slt-rd-hd mach Superseded by part number: 86625206
|
| 3. |
659229R91
|
[1] |
|
P
BASE ASSY, engine shutoff
|
| 4. |
659236R1
|
[2] |
|
P
WASHER, engine shutoff spring
|
| 5. |
659233R1
|
[1] |
|
P
SPRING, engine shutoff contact
|
| 6. |
665186R2
|
[1] |
|
P
SUPPORT, engine shutoff
|
| 7. |
664547R91
|
[2] |
|
P
WIRE, lead 290 in. long
|
| 8. |
659234R1
|
[1] |
|
P
SPRING, engine shutoff actuator
|
| 9. |
140568
|
[3] |
CLAMP
|
IH
CLIP, No. 5 5/16 x 9/16 closed
|
