| 1. |
585857R91
|
[1] |
|
P
VALVE ASSY, 90 deg terminating, needle pivot bearing
|
| 1. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self tap, str lub
|
| 2. |
668555R1
|
[4] |
|
P
CLIP, 3/16 open
|
| . . |
166684
|
[4] |
COVER PLATE
|
PA
SCREW, 10-32 x 3/8 cd-pltd cr-rec rd-hd tap.
|
| 2. |
362120R1
|
[9] |
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
|
IH
CLIP, loom, for 3/8 bolt
|
| 4. |
668598R91
|
[1] |
|
P
VALVE ASSY, top and tee, left knotter shaft bearing
|
| 4. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 6. |
585856R91
|
[1] |
|
P
VALVE ASSY, top terminating, plunger stop pivot
|
| 11. |
580256R1
|
[1] |
ADAPTER,45 Degree, 1/8"-27
|
IH
1/8-27 PTF x 45 deg angle Superseded by part number: 217-1084
|
| 12. |
588291R91
|
[1] |
|
P
VALVE ASSY, 90 deg terminating, upper bill hook drive shaft
|
| 12. |
586983R1
|
[1] |
|
P
ADAPTER, 1/8-27 PTF x 90 deg angle
|
| 15. |
585854R91
|
[1] |
|
P
VALVE ASSY, top terminating, lower bill hook drive shaft
|
| 15. |
20204R1
|
[1] |
ADAPTER,90 Degree, 1/4"-1/8 NPTF
|
IH
1/4-28 male x 1/8 pipe female 90 deg elbow, replaces 668803R1 Superseded by part number: 219-402
|
| 17. |
585865R91
|
[1] |
|
P
VALVE ASSY, top and 180 deg, upper cord holder pinion shaft
|
| 17. |
585626R1
|
[1] |
|
P
ADAPTER, 1/8-27 PTF x 20 deg angle
|
| 19. |
580257R1
|
[1] |
ADAPTER,60 Degree, 1/8"-27
|
IH
1/8-27 PTF x 60 deg angle
|
| 34. |
585862R91
|
[1] |
|
P
VALVE ASSY, 180 deg, rear packer crank bearing
|
| 38. |
668732R91
|
[1] |
|
P
VALVE ASSY, top and tee, auger drive shaft
|
| 43. |
668731R91
|
[1] |
|
P
VALVE ASSY, top and tee, right knotter shaft bearing
|
| 45. |
668734R91
|
[1] |
|
P
ADAPTER ASSY, swivel
|
| 49. |
668730R91
|
[1] |
|
P
VALVE ASSY, 90 deg elbow, left auger relief and support bearing
|
| 52. |
192159
|
[1] |
SEAT BELT
|
KOB
CONNECTOR, 1/8-27 ball sleeve tube
|
| 53. |
668621R91
|
[1] |
|
P
PUMP, grease
|
| 54. |
444253
|
[1] |
TEE,1/8"-27 Fem x Male Run x Fem Br, Brass
|
IH
1/8-27 automotive pipe
|
| 55. |
585589R91
|
[1] |
|
P
INDICATOR, pressure
|
