| 1. |
585857R91
|
[1] |
|
P
VALVE ASSY, 90 deg terminating, needle pivot bearing
|
| 1. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self tap. str lub
|
| 2. |
668555R1
|
[7] |
|
P
CLIP, 3/16 open
|
| . . |
166684
|
[7] |
COVER PLATE
|
PA
SCREW, 10-32 x 3/8 cd-pltd cr-rec rd-hd tap
|
| 2. |
362120R1
|
[9] |
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
|
IH
CLILP, loom, for 3/8 bolt
|
| 4. |
668598R91
|
[1] |
|
P
VALVE ASSY, top and tee, left twister shaft bearing
|
| 4. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 6. |
585856R91
|
[1] |
|
P
VALVE ASSY, top terminating, plunger stop pivot
|
| 11. |
585854R91
|
[1] |
|
P
VALVE ASSY, top terminating, lower left wire hook shaft
|
| 11. |
586983R1
|
[1] |
|
P
ADAPTER, 1/8-27 PTF x 90 deg angle
|
| 12. |
588291R91
|
[1] |
|
P
VALVE ASSY, 90 deg terminating, upper left wire hook shaft
|
| 12. |
580256R1
|
[1] |
ADAPTER,45 Degree, 1/8"-27
|
IH
1/8-27 PTF x 45 deg angle Superseded by part number: 217-1084
|
| 19. |
585861R91
|
[1] |
|
P
VALVE ASSY, 180 deg, upper left wire holder shaft
|
| 21. |
668599R91
|
[1] |
|
P
VALVE ASSY, top and 90 deg, lower left disc pinion shaft
|
| 26. |
668600R91
|
[1] |
|
P
VALVE ASSY, tee, upper right wire holder shaft
|
| 40. |
585862R91
|
[1] |
|
P
VALVE ASSY, 180 deg, rear packer crank bearing
|
| 42. |
668731R91
|
[1] |
|
P
VALVE ASSY, top and tee, right twister shaft bearing
|
| 44. |
668734R91
|
[1] |
|
P
ADAPTER ASSY, swivel
|
| 46. |
585865R91
|
[1] |
|
P
VALVE ASSY, top and 180 deg, auger drive shaft
|
| 53. |
668730R91
|
[1] |
|
P
VALVE ASSY, 90 deg elbow, left auger relief and support bearing
|
| 56. |
192159
|
[1] |
SEAT BELT
|
KOB
CONNECTOR, 1/8-27 ball sleeve tube
|
| 57. |
668621R91
|
[1] |
|
P
PUMP, grease
|
| 58. |
444253
|
[1] |
TEE,1/8"-27 Fem x Male Run x Fem Br, Brass
|
IH
1/8-27 automotive pipe
|
| 59. |
585589R91
|
[1] |
|
P
INDICTOR, pressure
|
