凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-64[A]) - FUEL TANK AND CONNECTIONS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
510 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
23995DC
|
[1] |
FILLER CAP
|
IH
CAP, fuel tank filler Superseded by part number: 9701704
|
| 2. |
23977DB
|
[1] |
GASKET
|
IH
fuel tank filler cap Superseded by part number: 23977DD
|
| 3. |
61647DDX
|
[1] |
TANK ASSY, fuel
|
|
| 4. |
277340R2
|
[1] |
|
P
TUBE, fuel strainer
|
| 5. |
19985R1
|
[2] |
TUBE NUT,1/2"-20
|
IH
NUT, 5/16-24 hi-duty tube
|
| 6. |
369988R91
|
[1] |
FILTER CARTRIDGE
|
IH
STRAINER ASSY, fuel Superseded by part number: 61782C91
|
| 7. |
49947D
|
[1] |
COLLAR CLAMP
|
IH
BAIL, strainer
|
| 8. |
50061D
|
[1] |
NUT
|
IH
strainer Superseded by part number: A11210
|
| 9. |
357958R1
|
[1] |
BOWL
|
IH
strainer
|
| 10. |
360679R1
|
[1] |
GASKET
|
IH
strainer Superseded by part number: A11208
|
| 11. |
49923D
|
[1] |
FILTER SCREEN
|
IH
SCREEN, strainer
|
| 12. |
259403R91
|
[1] |
COCK
|
IH
STEM ASSY, strainer
|
| 13. |
275084R1
|
[2] |
|
P
PAD, fuel tank
|
| . . |
55223D
|
[1] |
|
P
LOOM, fuel strainer tube
|
