凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-65) - AIR CLEANER & CONNECTIONS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
198 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
353410R92
|
[1] |
RETAINER
|
IH
PRE-SCREENER ASSY, air cleaner
|
| 2. |
353637R91
|
[1] |
SCREEN
|
IH
SCREW W/CLIP, 353758R1 and two springs, 353639R1, pre-screener
|
| 3. |
353639R1
|
[2] |
VALVE SPRING
|
IH
SPRING, screen lock tension
|
| 4. |
353758R1
|
[1] |
CLIP
|
IH
screen lock tension spring
|
| 5. |
366321R91
|
[1] |
CLEANER
|
IH
ASSY, air
|
| . . |
179837
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
IH
Superseded by part number: 86500692
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
Q1597
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga Superseded by part number: 86632580
|
| 6. |
352597R91
|
[1] |
BOWL
|
IH
CUP, oil
|
| 7. |
66357DA
|
[1] |
CLAMP
|
IH
oil cup retaining
|
| 8. |
366322R1
|
[1] |
INTAKE AIR HOSE,1.62" ID x 1.56", SAE 20R1 Class R
|
IH
Air Cleaner to Carburetor 1.62" ID x 1.56", SAE 20R1 Class R
|
| 9. |
274087R91
|
[2] |
HOSE CLAMP,1.50/2.38 Type F Worm
|
IH
CLAMP, air cleaner to carburetor hose Superseded by part number: 84674
|
