1107738
|
[1] |
MOTOR ASSEMBLY, cranking, 662648R91, 12 volt
|
|
| . . |
179883
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
Superseded by part number: 180175
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 1. |
810819
|
[1] |
PLUG
|
IH
end Superseded by part number: A185105
|
| 2. |
1872678
|
[1] |
BUSHING
|
IH
commutator end Superseded by part number: 1891927
|
| 3. |
1940385
|
[1] |
FUNNEL
|
IH
FRAME ASSEMBLY, commutator end, composed of, (1) bushing 1872678, (1) frame (NSS), (1) plug 453465, (1) plug 810819, (1) wick 1919851 Superseded by part number: A25304
|
| 4. |
1919851
|
[1] |
WICK
|
IH
end frame Superseded by part number: A41979
|
| 5. |
453465
|
[1] |
PLUG, end frame pipe
|
|
| 6. |
1926618
|
[2] |
HOLDER
|
IH
brush insulated Superseded by part number: A49472
|
| 7. |
1926622
|
[2] |
VALVE SPRING
|
IH
SPRING, brush Superseded by part number: A25359
|
| 8. |
1926617
|
[2] |
BRUSH HOLDER
|
IH
HOLDER, brush ground Superseded by part number: 1940477
|
| 9. |
1906945
|
[4] |
COMMUTATOR BRUSH
|
IH
BRUSH Superseded by part number: A20893
|
| 10. |
1926648
|
[4] |
SCREW, brush attaching
|
|
| 11. |
1926600
|
[2] |
PIN
|
CAS
support attaching Superseded by part number: 1966923
|
| 12. |
1926605
|
[2] |
ELECTRICAL WIRE
|
IH
LEAD, brush ground Superseded by part number: A42494
|
| 13. |
120361
|
[4] |
NUT,Hex Mach Screw, #10 - 24
|
IH
Support attaching screw #10-24 Superseded by part number: 87304
|
| 14. |
120217
|
[4] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, , Support attaching screw #10 Superseded by part number: 80684
|
| 15. |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
SCREW, support attaching
|
| 16. |
1928015
|
[2] |
BRACKET
|
IH
KIT, brush holder support Superseded by part number: A25379
|
| 17. |
1917084
|
[1] |
SCREW
|
IH
field lead, Serial Range: attaching-connector Superseded by part number: 113955
|
| 18. |
131183
|
[1] |
|
P
WASHER, field lead attaching to connector screw lock
|
| 19. |
1926604
|
[1] |
GROMMET, connector
|
|
| 20. |
1935314
|
[1] |
CONNECTOR, switch
|
|
| 21. |
1467
|
[1] |
SWITCH
|
CAS
ASSEMBLY, solenoid Superseded by part number: 1114545
|
| 22. |
1928969
|
[1] |
FORK
|
BER
FIELD COIL ASSEMBLY
|
| 23. |
833602
|
[1] |
WASHER
|
IH
commutator end packing Superseded by part number: 1914842
|
| 24. |
1935588
|
[1] |
|
P
ARMATURE
|
| 25. |
124546
|
[1] |
WOODRUFF KEY,#6, 5/32" x 5/8", HT
|
IH
Superseded by part number: 126-112
|
| 26. |
809815
|
[1] |
WASHER
|
IH
drive end space, 5/8 x 1-1/16 x 1/16
|
| 27. |
1849774
|
[1] |
WASHER
|
CAS
drive end space, 5/8 x 1-1/16 x 3/32 Superseded by part number: 809815
|
| 28. |
1853917
|
[1] |
WASHER, drive end thrust
|
|
| 29. |
1945564
|
[1] |
HOUSING ASSEMBLY, drive end
|
|
| 30. |
810620
|
[1] |
BUSHING
|
IH
drive end housing
|
| 31. |
809593
|
[1] |
PIN
|
IH
drive end dowel
|
| 32. |
1882486
|
[1] |
DRIVE
|
IH
ASSEMBLY, motor
|
| 33. |
1927853
|
[4] |
FOAM INSULATION
|
IH
INSULATOR, field coil Superseded by part number: 1976832
|
| 34. |
1913960
|
[4] |
SCREW
|
IH
pole shoe Superseded by part number: 1968396
|
| 35. |
1926616
|
[4] |
SHOE
|
CAS
pole
|
