凯斯零件查询(57) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/57-12/72) (A-71) - CRANKING MOTOR, DELCO REMY, 6 VOLT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
868 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
1107490
|
[1] |
MOTOR ASSY, cranking, 356726R92, 6 volt
|
|
| . . |
179883
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
Superseded by part number: 180175
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 1. |
1928966
|
[1] |
FRAME
|
IH
commutator end Superseded by part number: 1974157
|
| 2. |
1926618
|
[2] |
HOLDER
|
IH
insulated brush Superseded by part number: A49472
|
| 3. |
1926622
|
[2] |
VALVE SPRING
|
IH
SPRING, brush Superseded by part number: A25359
|
| 4. |
1926617
|
[2] |
BRUSH HOLDER
|
IH
HOLDER, ground brush Superseded by part number: 1940477
|
| 5. |
1906966
|
[4] |
BRUSH
|
CAS
Superseded by part number: 1906945
|
| 6. |
1926648
|
[4] |
SCREW, brush attaching
|
|
| 7. |
1926605
|
[2] |
ELECTRICAL WIRE
|
IH
LEAD, ground brush Superseded by part number: A42494
|
| 8. |
1928015
|
[2] |
BRACKET
|
IH
KIT, brush holder support Superseded by part number: A25379
|
| 9. |
1465
|
[1] |
SWITCH
|
CAS
ASSY, solenoid Superseded by part number: 142364HA
|
| . . |
1916529
|
[2] |
SCREW
|
IH
switch attaching
|
| 10. |
1935314
|
[1] |
CONNECTOR, switch
|
|
| 11. |
1926604
|
[1] |
GROMMET, in field frame
|
|
| 12. |
1959303
|
[1] |
FIELD COIL ASSY, 4 coils
|
|
| 13. |
833602
|
[1] |
WASHER
|
IH
commutator end space Superseded by part number: 1914842
|
| 14. |
818002
|
[1] |
ARMATURE
|
IH
|
| 15. |
124546
|
[1] |
WOODRUFF KEY,#6, 5/32" x 5/8", HT
|
IH
Superseded by part number: 126-112
|
| 16. |
1882486
|
[1] |
DRIVE
|
IH
ASSY, motor
|
| 17. |
809815
|
[1] |
WASHER
|
IH
drive end space, 5/8 x 1-1/16 x 1/16
|
| 18. |
1849774
|
[1] |
WASHER
|
CAS
drive end spacer, 5/8 x 1-1/16 x 3/32 Superseded by part number: 809815
|
| 20. |
1945564
|
[1] |
HOUSING ASSY, drive end
|
|
| 21. |
810620
|
[1] |
BUSHING
|
IH
drive end housing
|
| 22. |
809593
|
[1] |
PIN
|
IH
drive end dowel
|
| 23. |
1881869
|
[4] |
SCREW
|
CAS
pole shoe Superseded by part number: 1968396
|
| 24. |
810601
|
[4] |
SHOE, pole
|
|
| 25. |
1926625
|
[2] |
BOLT
|
CAS
thru Superseded by part number: 1939970
|
