| 1. |
360053R92
|
[1] |
INDICATOR
|
IH
ASSY, charge Superseded by part number: 378424R91
|
| 2. |
379594R92
|
[1] |
SWITCH
|
IH
ASSY, ignition key Superseded by part number: 403562R2
|
| . . |
365502R1
|
[1] |
NUT
|
IH
ignition key switch mounting
|
| . . |
375431R1
|
[1] |
LOCK WASHER
|
IH
ignition key swtich mounting nut
|
| 3. |
366317R93
|
[1] |
SWITCH
|
IH
ASSY, push button starting
|
| 3. |
366317R93GV
|
[1] |
CONTROL
|
MKT
Value, Control Switch
|
| . . |
120611
|
[2] |
NUT,#10 - 32
|
IH
10-32 C-Z sq Superseded by part number: 87825
|
| . . |
132903
|
[2] |
ADAPTER
|
PA
SCREW, 10-32 x 7/16 C-Z slt-rd-hd mach
|
| . . |
120217
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 4. |
391617R91
|
[1] |
|
P
CABLE ASSY, magnetic switch to charge indicator
|
| 5. |
391615R91
|
[1] |
|
P
CABLE ASSY, charge, indicator to voltage regulator bat. terminal
|
| 7. |
376869R91
|
[1] |
CABLE
|
IH
ASSY, key switch to push button switch Superseded by part number: 405222R1
|
| 8. |
391618R91
|
[1] |
|
P
CABLE ASSY, push button switch to magnetic switch
|
| 9. |
391613R91
|
[1] |
|
P
CABLE ASSY, voltage regulator F terminal to generator F terminal
|
| 10. |
391614R91
|
[1] |
|
P
CABLE ASSY, generator A terminal to voltage regulator gen terminal
|
| 11. |
391619R91
|
[1] |
|
P
CABLE ASSY, push button, Serial Range: switch-coil
|
| 12. |
370820R1
|
[2] |
CLIP
|
IH
cable
|
| 13. |
362120R1
|
[2] |
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
|
IH
CLIP, cable
|
| 14. |
671088R91
|
[1] |
|
P
CABLE ASSY, battery to solenoid switch
|
| 15. |
387258R91
|
[1] |
|
P
BATTERY, Prestolite 2005X, 12 volt
|
