| 1. |
306743R1
|
[1] |
|
P
HOOD, engine
|
| . . |
102635
|
[6] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
179837
|
[6] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
IH
Superseded by part number: 86500692
|
| . . |
103321
|
[6] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
95-11041
|
[6] |
WASHER,3/8"
|
CAS
13/32 x 13/16 x 16 ga Superseded by part number: 87016
|
| 2. |
356206R41
|
[1] |
|
P
SCREEN ASSY, radiator
|
| 3. |
355839R2
|
[1] |
|
P
SUPPORT, radiator & engine
|
| . . |
102639
|
[3] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
413-1036
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
SCREW, 5/8-11 x 2-1/4 hex-hd cap Superseded by part number: 88556
|
| . . |
271564
|
[2] |
BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 5
|
NNA
SCREW, 5/8-11 x 2-1/2 hex-hd cap Superseded by part number: 13-1040, 13-1040, NLS
|
| . . |
271566
|
[1] |
SUPPORT,Hex, 5/8" - 11 x 3", Gr 5
|
NNA
SCREW, 5/8-11 x 3 hex-hd cap Superseded by part number: 413-1048, 413-1048, NLS
|
| . . |
103325
|
[4] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 4. |
269448R21
|
[1] |
|
P
SUPPORT ASSY, hood front
|
| 5. |
278806R91
|
[1] |
|
P
SUPPORT ASSY, hood rear
|
| . . |
17412R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
SCREW, 3/8-16 x 3/4 hex-hd cap Superseded by part number: 86500692
|
| 6. |
274933R1
|
[2] |
|
P
FELT, radiator screen, short
|
| 7. |
274932R1
|
[2] |
|
P
FELT, radiator screen, long
|
