| 1. |
413-512
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 2. |
492-11031
|
[1] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 3. |
425-105
|
[1] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 4. |
766667
|
[1] |
BOLT,1/2" - 13 x 10"
|
CAS
1/2 X 10 EYE BOLT
|
| 5. |
27342
|
[1] |
GRIP
|
CAS
- handle
|
| 6. |
700113054
|
[1] |
LEVER
|
CAS
HANDLE WA
|
| 7. |
432-1224
|
[2] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
3/16" x 1 1/2" Superseded by part number: 80754
|
| 8. |
6489231
|
[2] |
SPACER
|
CAS
|
| 9. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 10. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 11. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 12. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 13. |
231-1448
|
[2] |
NUT,1/2"-13, GB
|
CAS
1/2-13 LHSN Superseded by part number: 87530607
|
| 14. |
700113057
|
[1] |
PIN
|
CAS
- brake
|
| 15. |
700113052
|
[1] |
STOP
|
CAS
|
| 16. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 17. |
432-1016
|
[1] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 18. |
700113058
|
[1] |
BRAKE BAND
|
CAS
BRAKE ASSEMBLY
|
| 19. |
433-820
|
[6] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 20. |
80679
|
[14] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 21. |
425-108
|
[11] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 22. |
51318
|
[1] |
BEARING
|
IH
Superseded by part number: 668718R92, 47577169
|
| 23. |
700113022
|
[1] |
SUPPORT
|
CAS
|
| 24. |
413-820
|
[7] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 25. |
700110467
|
[1] |
BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm
|
L
BEARING ASSEMBLY (Includes item 22)
|
| 26. |
413-872
|
[1] |
BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5
|
CAS
1/2-13 X 4-1/2 C Superseded by part number: 87996
|
| 27. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 28. |
700112893
|
[1] |
CHANNEL
|
CAS
WA
|
| 29. |
6524003
|
[1] |
SPACER
|
CAS
|
| 30. |
439-5848
|
[1] |
HEADED PIN,1/2" x 3", G5
|
CAS
1/2 X 3 CLEVIS PIN Superseded by part number: 86979987
|
| 31. |
326-1048
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 8
|
CAS
|
| 32. |
232-53110
|
[1] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/C Superseded by part number: 84180923
|
