凯斯零件查询(8580) - CASE IH LARGE RECTANGULAR BALER (1/88-12/98) (02-10) - DRIVELINE ASSEMBLY, IMPLEMENT, 1000 RPM-TYPE 3 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
724 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700715955
|
[1] |
YOKE
|
CAS
U-JOINT ASSEMBLY - half, implement
|
| 2. |
700715954
|
[1] |
YOKE
|
CAS
U-JOINT ASSEMBLY - half, tractor
|
| 3. |
700706953
|
[1] |
SHIELD
|
CAS
- inner
|
| 4. |
700712579
|
[2] |
BEARING ASSY
|
CAS
BEARING AND RETAINER KIT Superseded by part number: 86505713
|
| 5. |
219-40
|
[2] |
LUBE NIPPLE,65 Degree Elbow, 1/8" - 27 NPTF
|
CAS
1/8 PTF X 65 DEGREE ZERK Superseded by part number: 80711
|
| 6. |
470077R91
|
[2] |
BEARING ASSY,1.025" ID x 1.5325" OD x 4.309"
|
IH
CROSS AND BEARING KIT (Includes item 5) Superseded by part number:
|
| 7. |
8802613
|
[1] |
SHAFT
|
CAS
YOKE - shaft
|
| 8. |
1326528C1
|
[1] |
DECAL
|
IH
- danger, shield missing Superseded by part number: 849472
|
| 9. |
700706954
|
[1] |
SHIELD
|
CAS
- outer
|
| 10. |
80672C1
|
[1] |
DECAL
|
IH
- danger, rotating driveline Superseded by part number: 849471
|
| 11. |
700712517
|
[2] |
YOKE
|
CAS
1-3/4" X 20 SPLINE YOKE - implement
|
| 12. |
8802621
|
[1] |
YOKE,66.68 mm OD x 508.00 mm L
|
CAS
AND TUBE
|
