凯斯零件查询(8580) - CASE IH LARGE RECTANGULAR BALER (1/88-12/98) (02-16) - GEARBOX MOUNTING ASSEMBLY, S.N. CFH0026001 THRU CFH0026170 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
491 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700113066
|
[2] |
PIN
|
CAS
|
| 2. |
700706062
|
[3] |
SHIM
|
CAS
0.08/.003
|
| 3. |
700706063
|
[6] |
SHIM
|
CAS
0.13/.005
|
| 4. |
700706064
|
[6] |
SHIM
|
CAS
0.25/.010
|
| 5. |
700113042
|
[4] |
SPACER
|
CAS
|
| 6. |
413-1244
|
[4] |
BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5
|
CAS
3/4-10 X 2-3/4 C Superseded by part number: 80280173
|
| 7. |
492-11075
|
[4] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 8. |
7771504
|
[2] |
BOLT
|
CAS
5/8-11 X 3 FTC
|
| 9. |
425-1010
|
[4] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 10. |
700112934
|
[1] |
GEARBOX
|
CAS
ASSEMBLY (Superseded by 700122641 and 700122660) Superseded by part number: 700122659, 700122641
|
| 11. |
700113051
|
[1] |
TUBE,38.1 mm OD, 230 mm Length
|
CAS
|
| 12. |
232-41116
|
[2] |
LOCK NUT,1"-8, GC
|
CAS
NUT, LOCK, 1"-8, GC Superseded by part number: 9626600
|
| 13. |
192-171
|
[2] |
LOCK WASHER,1"
|
CAS
WASHER, LOCK, 1" Superseded by part number: 92-21100
|
| 14. |
700113047
|
[2] |
PIN
|
CAS
WA
|
| 15. |
326-1672
|
[2] |
BOLT,Hex, 1" - 8 x 4-1/2", Gr 8
|
CAS
|
