沃尔沃零件查询MD31A; TMD31A; TMD31B; TAMD31A; TAMD31B; AD31; AQAD31A; AD31B; 290A; DP-A; DP-B; DP-A1; DP-B1; SP-A; SP-A1Cooling SystemAfter Cooler and Installation Components: AEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
590 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
838823
|
[1] |
Housing, housing
|
For insert 838718 or insert 858947 together with seal ring 858979
|
| 1. |
|
|
|
Repl by 859199
|
| 1. |
858948
|
[1] |
Housing, housing
|
For insert 858947 together with seal ring 858979., SN-2203104513
|
| 1. |
859199
|
[1] |
Housing
|
For insert 838718 together with seal ring 858979 or insert 858947 together with seal ring 858979, Re
|
| 1. |
859354
|
[1] |
Housing
|
SN2203109021-
|
| 2. |
838718
|
[1] |
Insert
|
For housing 838823 or housing 859199
|
| 2. |
|
|
|
Repl by 858947
|
| 2. |
858947
|
[1] |
Insert
|
For housing 858948 or housing 859199, Repl by 859362
|
| 2. |
859362
|
[1] |
Insert
|
For housing 858948 or housing 859199
|
| 3. |
838720
|
[1] |
Seal
|
|
| 4. |
838831
|
[1] |
Sealing strip
|
|
| 5. |
838720
|
[1] |
Seal
|
|
| 6. |
847573
|
[1] |
Sealing strip
|
|
| 7. |
859554
|
[1] |
Cover
|
Replaced by cover 860135 and mounting kit 876293., Metal
|
| 7A. |
948685
|
[12] |
Cap nut
|
|
| 8. |
953031
|
[11] |
Stud
|
L=25mm early type
|
| 8. |
953032
|
[12] |
Stud
|
L=28mm late type
|
| 9. |
860135
|
[1] |
Cover
|
Plastic
|
| 10. |
876293
|
[1] |
Mounting kit
|
For 860135
|
| 10A. |
860133
|
[1] |
Retainer
|
For 860135
|
| 10B. |
953036
|
[11] |
Stud
|
L=38mm
|
| 10. |
975132
|
[1] |
Stud
|
L=68mm
|
| 10C. |
955893
|
[12] |
Washer
|
|
| 11. |
1619957
|
[1] |
Gasket
|
(324359) SN-2203104513
|
| 12. |
192134
|
[1] |
Plug
|
SN-2203104513
|
| 13. |
858945
|
[1] |
Cover
|
Replaced by seal ring 858979., SN-2203104513
|
| 14. |
953041
|
[1] |
Stud
|
|
| 15. |
945408
|
[1] |
Flange nut
|
|
| 16. |
838833
|
[1] |
Support
|
|
| 17. |
838754
|
[1] |
Bracket
|
For 859554
|
| 18. |
858979
|
[1] |
Sealing ring
|
|
| 19. |
838819
|
[1] |
Coolant pipe
|
Oil cooler-after cooler
|
| 20. |
838779
|
[1] |
Coolant pipe
|
After cooler-heat exchanger, Productno.868321,868325,868327
|
| 20. |
838816
|
[1] |
Coolant pipe
|
After cooler-reverse gear, Replaced by pipe 860279,860280 and mounting kit 859588.
|
| 20. |
860279
|
[1] |
Coolant pipe
|
(859585) see group 4A
|
| 21. |
847108
|
[2] |
Pipe retainer
|
|
| 22. |
858986
|
[4] |
Sealing ring
|
(842744)
|
| 23. |
946472
|
[1] |
Flange screw
|
|
| 24. |
838828
|
[1] |
Anchorage
|
|
| 25. |
952635
|
[2] |
Clamp
|
|
| 26. |
946544
|
[1] |
Flange screw
|
|
| 27. |
952635
|
[1] |
Clamp
|
|
| 28. |
|
|
|
See group 2A
|
| 29. |
965175
|
[2] |
Flange screw
|
SN-2203104513
|
| 30. |
949918
|
[1] |
Shut-off cock
|
Early type
|
| 30A. |
192134
|
[1] |
Plug
|
Late type
|
| 31. |
858944
|
[1] |
Anchorage
|
|
| 32. |
946934
|
[1] |
Flange screw
|
|
| 33. |
945407
|
[1] |
Flange nut
|
|
| 34. |
949918
|
[1] |
Shut-off cock
|
For pipe 838779
|
| 35. |
859593
|
[1] |
Mounting kit
|
|
| 36. |
858967
|
[1] |
Bracket
|
For 859354
|
| 37. |
858965
|
[1] |
Bracket
|
For 859354
|
| 38. |
912142
|
[2] |
Spacer sleeve
|
L=5mm
|
| 39. |
965226
|
[2] |
Flange screw
|
|
| 40. |
955897
|
[2] |
Washer
|
Early type
|
| 41. |
953041
|
[2] |
Stud
|
|
| 42. |
945408
|
[2] |
Flange nut
|
|
| 43. |
946934
|
[1] |
Flange screw
|
|
| 44. |
945407
|
[1] |
Flange nut
|
|
| 45. |
946329
|
[1] |
Flange screw
|
|
