| 1. |
700716699
|
[4] |
BOLT
|
CAS
7/8-9 X 12 C GR8
|
| 2. |
96-11094
|
[8] |
WASHER,0.94" ID x 1.75" OD x 0.13" Thk
|
CAS
7/8 HARDENED PLAIN WASHER
|
| 3. |
700137103
|
[2] |
ARM
|
CAS
WA - crank
|
| 4. |
700137106
|
[2] |
SPACER
|
CAS
- brg, crank arm
|
| 5. |
429-1014
|
[4] |
NUT,7/8"-9, G8
|
CAS
7/8-9 H GR8 Superseded by part number: 280881
|
| 6. |
425-1014
|
[4] |
NUT,7/8"-9, G5
|
CAS
NUT, 7/8"-9, G5 Superseded by part number: 9849647
|
| 7. |
700708038
|
[2] |
SHIM,150mm ID x 180mm OD x 0.25mm Thk
|
CAS
- 0.25/.010
|
| 8. |
700708039
|
[2] |
SHIM
|
CAS
- 0.64/.025
|
| 9. |
700708041
|
[2] |
SHIM,150mm ID x 180mm OD x 1.21mm Thk
|
CAS
- 1.2/.048
|
| 10. |
700706050
|
[1] |
O-RING
|
CAS
|
| 11. |
700706056
|
[1] |
SHIM
|
CAS
- 0.08/.003
|
| 12. |
700706058
|
[1] |
SHIM
|
CAS
- 0.25/.010
|
| 13. |
700706057
|
[1] |
SHIM
|
CAS
- 0.13/.005
|
| 14. |
700707991
|
[1] |
SHIM,63.5mm ID x 95mm OD x 0.51mm Thk
|
CAS
- 0.51/.020
|
| 15. |
700137135
|
[1] |
HUB
|
CAS
- shear
|
| 16. |
700706059
|
[1] |
SHIM
|
CAS
0.08/.003
|
| 17. |
700707993
|
[1] |
SHIM
|
CAS
0.51/.020
|
| 18. |
700706061
|
[1] |
SHIM
|
CAS
0.25/.010
|
| 19. |
700706060
|
[1] |
SHIM
|
CAS
0.13/.005
|
| 20. |
700113044
|
[1] |
RETAINING PLATE
|
CAS
CAP - retainer
|
| 21. |
700113045
|
[1] |
LOCKING PLATE
|
CAS
TAB - lock
|
| 22. |
628-16040
|
[2] |
BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd
|
CAS
|
| 23. |
700124039
|
[1] |
BALER FLYWHEEL
|
CAS
FLYWHEEL ASM (Includes items 29 and 30) Superseded by part number: 700152213
|
| 24. |
219-8
|
[3] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 25. |
700706045
|
[1] |
SEAL
|
CAS
|
| 26. |
6521868
|
[1] |
BOLT
|
CAS
7/16-14 X 2 1/8 LOCK THREAD SPL Superseded by part number: 226228
|
| 27. |
429-107
|
[1] |
NUT,7/16"-14, G8
|
CAS
|
| 28. |
78848C91
|
[2] |
BEARING ASSY,61.98mm ID x 24.61mm W
|
IH
CONE - bearing
|
| 29. |
7852718
|
[1] |
SLEEVE
|
CAS
- shear Superseded by part number: 196727
|
| 30. |
610513C1
|
[2] |
BEARING CUP,101.6mm OD x 19.84mm W
|
IH
BEARING - cup
|
| 31. |
700137107
|
[1] |
WASHER
|
CAS
- special
|
| 32. |
413-1296
|
[1] |
BOLT,Hex, 3/4" - 10 x 6", Gr 5
|
CAS
3/4-10 X 6 C Superseded by part number: 280120
|
| 33. |
705566
|
[1] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 34. |
232-41112
|
[1] |
NUT,3/4"-10, GC
|
CAS
NUT, LOCK, 3/4"-10, GC Superseded by part number: 280375
|
| 35. |
700720000
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASSEMBLY Superseded by part number: 700161330, 700161330, 700715965, 700161330, 700715965, 700721657
|
