凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (2-16) - GEARBOX MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
776 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-820
|
[3] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
80679
|
[3] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 3. |
7771504
|
[2] |
BOLT
|
CAS
5/8-11 X 3 FTC
|
| 4. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 5. |
326-1672
|
[2] |
BOLT,Hex, 1" - 8 x 4-1/2", Gr 8
|
CAS
|
| 6. |
232-41116
|
[2] |
LOCK NUT,1"-8, GC
|
CAS
NUT, LOCK, 1"-8, GC Superseded by part number: 9626600
|
| 7. |
700113047
|
[2] |
PIN
|
CAS
WA
|
| 8. |
700122653
|
[2] |
SHIM
|
CAS
|
| 9. |
700122654
|
[2] |
SHIM
|
CAS
|
| 10. |
700137136
|
[1] |
TUBE,38.1 mm OD, 212 mm Length
|
CAS
|
| 11. |
700706062
|
[4] |
SHIM
|
CAS
.076/.003
|
| 12. |
700706063
|
[4] |
SHIM
|
CAS
.13/.005
|
| 13. |
700706064
|
[4] |
SHIM
|
CAS
.25/.010
|
| 14. |
700122650
|
[2] |
PIN
|
CAS
|
| 15. |
700113042
|
[4] |
SPACER
|
CAS
|
| 16. |
413-1264
|
[4] |
BOLT,Hex, 3/4" - 10 x 4", Gr 5
|
CAS
3/4-10 X 4 C Superseded by part number: 280210
|
| 17. |
230-41112
|
[4] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-10 HTLN GRB Superseded by part number: 280375
|
