700720000
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASSEMBLY COMPLETE Superseded by part number: 700161330, 700161330, 700715965, 700161330, 700715965, 700721657
|
| 1. |
7703259
|
[12] |
BOLT
|
CAS
M12 X 1.75 X 50 C Superseded by part number: 9706702
|
| 2. |
700706045
|
[2] |
SEAL
|
CAS
|
| 3. |
700715985
|
[1] |
SEAL
|
CAS
CARRIER - brg, seal
|
| 4. |
700720024
|
[1] |
O-RING
|
CAS
|
| 5. |
700706065
|
[1] |
NUT
|
CAS
- stake
|
| 6. |
700706032
|
[1] |
WASHER
|
CAS
- special
|
| 7. |
700706030
|
[1] |
ROLLER BEARING,76.2mm ID x 48.26mm W
|
CAS
CONE - bearing
|
| 8. |
700706034
|
[1] |
BEARING CUP,161.93mm OD x 38.1mm W
|
CAS
CUP - bearing
|
| 9. |
700715983
|
[1] |
CARRIER FLANGE SEAL
|
CAS
CARRIER - brg, seal
|
| 10. |
700720023
|
[2] |
O-RING
|
CAS
|
| 11. |
700706029
|
[1] |
BEARING CUP
|
CAS
CUP - bearing Superseded by part number: CASA140553
|
| 12. |
700706027
|
[1] |
ROLLER BEARING,84.138 mm ID x 46.038 mm
|
CAS
CONE - bearing
|
| 13. |
700715693
|
[2] |
GEAR
|
CAS
PINION - bevel & ring-gear
|
| 14. |
700720026
|
[1] |
PACKAGE
|
CAS
PACK - shim, carrier
|
| 15. |
700715541
|
[1] |
PINION
|
CAS
Superseded by part number: 700161330, 700161330, 700715965, 700161330, 700715965, 700721659
|
| 16. |
700715743
|
[1] |
ROLLER BEARING,110 mm ID x 46 mm
|
CAS
CONE - bearing
|
| 17. |
700715745
|
[1] |
BEARING, CUP,180 mm OD x 38 mm
|
CAS
CUP - bearing
|
| 18. |
700720008
|
[1] |
PACKAGE
|
CAS
PACK - shim, intermediate, right
|
| 19. |
700720025
|
[1] |
RING
|
CAS
O-RING
|
| 20. |
700720005
|
[1] |
CAP
|
CAS
- bearing, interm
|
| 21. |
614-12030
|
[62] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 22. |
700715746
|
[1] |
SEAL
|
CAS
|
| 23. |
700112988
|
[2] |
SPACER
|
CAS
- output
|
| 24. |
700708037
|
[2] |
SNAP RING
|
CAS
RING - retaining, spirolox
|
| 25. |
700137100
|
[1] |
SPACER
|
CAS
- right
|
| 26. |
238-5257
|
[2] |
O-RING,0.139" Thk x 5.859" ID, -257, Cl 5, 75 Duro
|
CAS
Superseded by part number: 87016956
|
| 27. |
700708000
|
[2] |
SEAL
|
CAS
|
| 28. |
862-10055
|
[2] |
HEX SOC SCREW,M10 x 55mm, Cl 12.9
|
CAS
M10 X 1.5 X 55 HSHCS SPL
|
| 29. |
700137115
|
[1] |
SCRAPER
|
CAS
WA - right
|
| 30. |
700715542
|
[1] |
GEAR
|
CAS
- output
|
| 31. |
700137114
|
[1] |
SCRAPER
|
CAS
WA - left
|
| 32. |
700715543
|
[1] |
SHAFT
|
CAS
- output
|
| 33. |
700137099
|
[1] |
SPACER
|
CAS
- L
|
| 34. |
861-12060
|
[4] |
HEX SOC SCREW,M12 x 60mm, Cl 12.9
|
SUM
M12 X 1.75 X 60 HSHCS SPL Superseded by part number: 1355168
|
| 35. |
700716685
|
[2] |
BAR
|
CAS
- tensioner
|
| 36. |
8799280
|
[1] |
FILTER
|
CAS
|
| 37. |
700720001
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASM - machined
|
| 38. |
861-10060
|
[2] |
HEX SOC SCREW,M10 x 60mm, Cl 12.9
|
CAS
M10 X 1.5 X 60 HSHCS SPL Superseded by part number: 108617
|
| 39. |
700706041
|
[2] |
SPHERICAL BEARING,150 mm ID x 225 mm OD x 56 mm
|
CAS
BEARING - roller
|
| 40. |
238-5270
|
[2] |
O-RING,0.139" Thk x 8.984" ID, -270, Cl 5, 75 Duro
|
CAS
Superseded by part number: 86625104
|
| 41. |
700112993
|
[2] |
SEAL
|
CAS
CAP - output
|
| 42. |
700706144
|
[1] |
DIPSTICK
|
CAS
GAGE - oil
|
| 43. |
700720006
|
[1] |
CAP
|
CAS
- bearing, interm
|
| 44. |
700720007
|
[1] |
PACKAGE
|
CAS
PACK - shim, intermediate, left
|
| 45. |
700715747
|
[1] |
SEAL
|
CAS
|
| 46. |
217-532
|
[1] |
DRAIN PLUG,Sq Hd, 1 1/4"-11 1/2 NPTF
|
CAS
PLUG, DRAIN, , Pipe Sq Hd, 1 1/4"-11 1/2 NPTF
|
| 47. |
700716952
|
[1] |
THERMOSTAT
|
CAS
ASSEMBLY
|
| 48. |
S118458
|
[1] |
BEARING, CUP,206.375 mm OD x 34.925 mm
|
CAS
CUP - bearing
|
| 49. |
700715742
|
[1] |
ROLLER BEARING,128.588 mm ID x 47.63 mm
|
CAS
CONE - bearing
|
