凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (2-24) - SHAFT AND SPROCKET ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
226 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700137396
|
[2] |
SLEEVE
|
CAS
- shear bolt
|
| 2. |
413-1024
|
[2] |
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 88062
|
| 3. |
700137407
|
[1] |
PLATE, LOCKING
|
CAS
TAB - lock
|
| 4. |
700137408
|
[1] |
CAP
|
CAS
- retainer
|
| 5. |
700716247
|
[1] |
SHIM
|
CAS
0.51/.020
|
| 6. |
413-1048
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
Superseded by part number: 87338
|
| 7. |
232-53110
|
[1] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 8. |
700716244
|
[2] |
SHIM
|
CAS
0.076/.003
|
| 9. |
700716245
|
[1] |
SHIM
|
CAS
0.130/.0051
|
| 10. |
700716246
|
[1] |
SHIM
|
CAS
0.25/.010
|
| 11. |
700137399
|
[1] |
HUB
|
CAS
ASSEMBLY (Includes item 1)
|
| 12. |
700137397
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET ASM - 100B40 tooth (Includes items 1, 14 and 15)
|
| 13. |
219-56
|
[1] |
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
|
CAS
1/8-27 X 90° ZERK
|
| 14. |
495-81205
|
[1] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 14 GAUGE NRMB
|
| 15. |
700112933
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 16. |
700137390
|
[1] |
ARM
|
CAS
- wa
|
| 17. |
700716267
|
[2] |
SEALING RING COLLAR
|
CAS
SEAL - excluder
|
| 18. |
65720C91
|
[2] |
BEARING ASSY,3.1496" ID x 5.1181" OD x 1.378"
|
IH
CONE - bearing Superseded by part number: 384141
|
| 19. |
65721C1
|
[2] |
BEARING ASSY,3.1496" ID x 5.1181" OD x 1.378"
|
IH
- cup Superseded by part number: 384141
|
| 20. |
700137393
|
[1] |
HUB
|
CAS
ASSEMBLY (Includes item 19)
|
