凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (3-18) - ANGLE ASSEMBLY, RIGHT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
618 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
434-616
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 2. |
496-11041
|
[8] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 3. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 4. |
61-736
|
[1] |
HEX SOC SCREW,7/16"-14 x 2 1/4"
|
CAS
7/16-14 X 2-1/4 HSHCS SPL Superseded by part number: NH280993
|
| 5. |
704452
|
[1] |
SPRING
|
CAS
7/16-14 HFTLN GR/G Superseded by part number: 51200183, 51200183, 86629502
|
| 6. |
428-832
|
[1] |
BOLT,Hex, 1/2" - 20 x 2", Gr 8
|
CAS
1/2-20 X 2 C GR8 Superseded by part number: 87779103, 280564
|
| 7. |
700720050
|
[1] |
CAM FOLLOWER
|
CAS
BEARING - cam follower
|
| 8. |
700137750
|
[1] |
SPACER
|
CAS
|
| 9. |
700707867
|
[1] |
NUT
|
CAS
1/2-20 HFTLN GR/G Superseded by part number: 87033645
|
| 10. |
700137747
|
[1] |
CRANK
|
CAS
WA
|
| 11. |
700708095
|
[1] |
SPHERICAL BEARING
|
CAS
BEARING - spherical Superseded by part number: 47577195, 45876
|
| 12. |
581469R1
|
[2] |
FLANGE,Bearing
|
IH
- bearing
|
| 13. |
700137733
|
[1] |
ANGLE
|
CAS
WA - right
|
| 14. |
700716132
|
[8] |
TINE
|
CAS
- double
|
