| 1. |
700133120
|
[1] |
SHIELD
|
CAS
- left
|
| 2. |
700714706
|
[2] |
LATCH
|
CAS
- 90° turn (Includes nut)
|
| 3. |
413-58
|
[4] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 X 1/2 C Superseded by part number: 72187203, 88574
|
| 4. |
231-5145
|
[12] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 5. |
700108658
|
[4] |
SUPPORT
|
CAS
- hinge Superseded by part number: 700163299
|
| 6. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 7. |
700137769
|
[1] |
PANEL
|
CAS
WA - left
|
| 8. |
409-7512
|
[15] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 9. |
433-512
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 10. |
700137766
|
[1] |
COVER
|
CAS
WRAPPER - left
|
| 11. |
433-612
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 12. |
329-286
|
[3] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 13. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
- bearing
|
| 14. |
51292
|
[1] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
| 15. |
340-1108
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS GR60M
|
| 16. |
195-513
|
[4] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 17. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 18. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 19. |
700714529
|
[2] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 20. |
700711094
|
[1] |
DECAL
|
CAS
- drive, left
|
| 21. |
700137772
|
[1] |
CHUTE (DOWNWARD)
|
CAS
CHUTE WA Superseded by part number: 700157778
|
| 22. |
6474316
|
[1] |
PIN
|
CAS
- hinge
|
