| 1. |
700137763
|
[1] |
SUPPORT
|
CAS
|
| 2. |
700123808
|
[1] |
PIVOT
|
CAS
WA - cylinder
|
| 3. |
700113281
|
[1] |
SPACER
|
CAS
|
| 4. |
413-1248
|
[1] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
CAS
.75 X 3 UNC GR5 YZD Superseded by part number: 87337
|
| 5. |
230-41112
|
[1] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-10 HTLN GRB Superseded by part number: 280375
|
| 6. |
700711095
|
[1] |
DECAL
|
CAS
- drive, right
|
| 7. |
433-612
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 8. |
329-286
|
[4] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 9. |
700137765
|
[1] |
COVER
|
CAS
WRAPPER - right
|
| 10. |
433-512
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 11. |
231-5145
|
[16] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 12. |
121-115
|
[10] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 13. |
409-7512
|
[10] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 14. |
700137767
|
[1] |
PANEL
|
CAS
WA - right
|
| 15. |
6844344
|
[1] |
PIN
|
CAS
- hinge
|
| 16. |
413-58
|
[4] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 X 1/2 C Superseded by part number: 72187203, 88574
|
| 17. |
51292
|
[1] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
| 18. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
- bearing
|
| 19. |
340-1108
|
[2] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS GR60M
|
| 20. |
195-513
|
[2] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 21. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 22. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 23. |
700133121
|
[1] |
SHIELD
|
CAS
- right Superseded by part number: 700162029
|
| 24. |
700714706
|
[1] |
LATCH
|
CAS
- 90° turn (Includes nut)
|
| 25. |
700137764
|
[1] |
SHIELD
|
CAS
|
| 26. |
700137898
|
[1] |
SHIELD
|
CAS
|
| 27. |
434-616
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
