凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (4-04) - ROAD LIGHT ASSEMBLY, FRONT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
398 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
412-48
|
[2] |
CARRIAGE BOLT,Short Sq Nk 1/4" - 20 x 1/2", Gr 2
|
CAS
1/4-20 X 1/2 RHSNB Superseded by part number: 280700
|
| 2. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 3. |
183727C1
|
[1] |
CAP
|
IH
- plug, electric Superseded by part number: 87790970
|
| 4. |
121-108
|
[1] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 5. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 6. |
700716881
|
[1] |
HARNESS
|
CAS
- lights
|
| 7. |
121-226
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 8. |
232-5316
|
[3] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 10. |
515-25127
|
[5] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
