凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (8-08) - HYDRAULIC BALE DENSITY ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
497 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8046724
|
[2] |
FITTING
|
CAS
ADAPTER - straight (Includes item 12) Superseded by part number: 218-5099
|
| 2. |
8799280
|
[2] |
FILTER
|
CAS
|
| 3. |
700706392
|
[1] |
FLEXIBLE HOSE
|
CAS
LINE - hydraulic, rear
|
| 4. |
700708939
|
[4] |
CLAMP
|
CAS
- heavy duty
|
| 5. |
121-115
|
[4] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 6. |
232-5315
|
[4] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 7. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 8. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
515-25127
|
[2] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
| 10. |
218-5222
|
[1] |
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
|
CAS
Superseded by part number: 72186135, 129274
|
| 11. |
700716853
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 12. |
237-6008
|
[4] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 13. |
218-5128
|
[2] |
ELBOW,90° Elbow, 9/16" - 18 Male JIC x 3/4" - 16 Male ORB
|
CAS
(Incl. item 12) 90º, 9/16"-18, 37º x 3/4"-16, O-Ring Superseded by part number: 87329788
|
| 14. |
700715969
|
[2] |
CYLINDER
|
CAS
- hydraulic
|
