凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (8-10) - HYDRAULIC CYLINDER ASSEMBLY, DENSITY CONTROL, 700715969 HYDRAULIC CYLINDER COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
687 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700715969
|
[1] |
CYLINDER
|
CAS
HYDRAULIC CYLINDER COMPLETE (3.5 inch bore x 12 inch stroke)
|
| 1. |
700720074
|
[1] |
PISTON
|
CAS
Superseded by part number: 700720179
|
| 2. |
7036676
|
[1] |
NUT
|
CAS
- piston
|
| 3. |
700720068
|
[1] |
TUBE
|
CAS
|
| 4. |
700720069
|
[1] |
BASE
|
CAS
- cylinder
|
| 5. |
700720072
|
[4] |
TIE-ROD
|
CAS
ROD - tie
|
| 6. |
700720075
|
[1] |
ROD
|
CAS
|
| 7. |
700720071
|
[1] |
HEAD
|
CAS
- cylinder
|
| 8. |
811119C1
|
[2] |
PIN
|
IH
- clevis Superseded by part number: 87735776
|
| 9. |
700720070
|
[1] |
ROD
|
CAS
CLEVIS - rod Superseded by part number: 700715579
|
| 10. |
S120261
|
[2] |
PIN
|
CAS
.149 WIRE HAIR PIN COTTER
|
| 11. |
700720073
|
[1] |
SEAL
|
CAS
KIT Superseded by part number: 700720178
|
