凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (7-08) - TOP SHIELDS ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
844 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-820
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
230-4118
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HTLN GRB
|
| 3. |
121-115
|
[22] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 4. |
231-5145
|
[26] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 5. |
700137890
|
[1] |
SHIELD
|
CAS
- front
|
| 6. |
700137977
|
[1] |
SHIELD
|
CAS
|
| 7. |
121-108
|
[4] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 8. |
700137911
|
[1] |
LID
|
CAS
WA
|
