| 1. |
256873
|
[6] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 2. |
700137982
|
[1] |
SHIELD
|
CAS
ASM-IDL COVER
|
| 3. |
433-512
|
[8] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 4. |
496-21034
|
[6] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 5. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 6. |
700137906
|
[1] |
SHIELD
|
CAS
-IDL
|
| 7. |
413-528
|
[2] |
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707515, 72187200
|
| 8. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 9. |
700137985
|
[1] |
SHIELD
|
CAS
WA - panel Superseded by part number: 700140315, 700140313
|
| 10. |
700709866
|
[1] |
WASHER
|
CAS
- washer, camloc
|
| 11. |
758342
|
[1] |
CABLE
|
CAS
- compression Superseded by part number: CAS758342
|
| 12. |
700137803
|
[1] |
COVER
|
CAS
SHIELD - cover
|
| 13. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 14. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 15. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/B Superseded by part number: 86521609
|
| 16. |
700707234
|
[1] |
BUTTON
|
IH
KNOB - female
|
| 17. |
425-105
|
[2] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 18. |
6270888
|
[2] |
BUSHING
|
CAS
|
| 19. |
700138104
|
[1] |
SHIELD
|
CAS
WA
|
| 20. |
7758915
|
[1] |
SPRING
|
CAS
- extension
|
| 21. |
700137990
|
[1] |
SHAFT
|
CAS
WA - latch
|
| 22. |
190123C1
|
[1] |
SPACER,1/2" Tube x 1"
|
IH
|
| 23. |
495-61034
|
[2] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
