| 1. |
409-7612
|
[12] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 2. |
700710049
|
[5] |
WASHER
|
CAS
3/8 FENDER WASHER
|
| 3. |
231-5146
|
[12] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 4. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 5. |
433-612
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 6. |
329-286
|
[5] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 7. |
700137848
|
[1] |
SUPPORT
|
CAS
WA - lower, left
|
| 8. |
700720042
|
[2] |
STUD
|
CAS
5/16-18 STUD - 13 MM ball
|
| 9. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 10. |
700720035
|
[2] |
CLIP
|
CAS
- retainer 13MM
|
| 11. |
700137855
|
[1] |
SUPPORT
|
CAS
WA - upper, left
|
| 12. |
700720043
|
[1] |
SHOCK ABSORBER
|
CAS
SPRING - gas, 400 N
|
| 13. |
700137971
|
[1] |
PANEL
|
CAS
- shield, left
|
| 14. |
700137820
|
[1] |
SUPPORT
|
CAS
- mounting
|
| 15. |
100-11137
|
[2] |
SNAP RING,#137, Ext
|
CAS
Ring, Snap, #137, Ext Superseded by part number: 9671424
|
| 16. |
700137816
|
[2] |
GUIDE
|
CAS
- twine
|
| 17. |
700123922
|
[1] |
SUPPORT
|
CAS
- mounting
|
| 18. |
433-512
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 19. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 20. |
433-820
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 21. |
329-288
|
[6] |
FLANGE NUT,Flg, 1/2"-13, G8
|
CAS
|
| 22. |
700137949
|
[1] |
SUPPORT
|
CAS
WA - left
|
| 23. |
700137945
|
[1] |
SHIELD
|
CAS
- left, top
|
| 24. |
700137965
|
[1] |
SHIELD
|
CAS
- needle, left
|
| 25. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 26. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
