凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (7-28) - LADDER MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700138022
|
[1] |
RAIL
|
CAS
WA - lower, left
|
| 2. |
700137894
|
[1] |
LADDER
|
CAS
WA Superseded by part number: 700138102
|
| 3. |
433-612
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 4. |
329-286
|
[12] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 5. |
700138132
|
[1] |
SHIELD
|
CAS
- needle, left
|
| 6. |
434-612
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSSNB Superseded by part number: 86508748
|
| 7. |
281-34912
|
[1] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHTCTS
|
| 8. |
700137888
|
[1] |
SUPPORT
|
CAS
|
| 9. |
413-532
|
[2] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
Superseded by part number: 9636711
|
| 10. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 11. |
700138031
|
[1] |
PIPE
|
CAS
- rail, lower right
|
| 12. |
700708407
|
[1] |
PLUG
|
CAS
|
| 13. |
409-7612
|
[4] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 14. |
231-5146
|
[4] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
