| 1. |
700137344
|
[1] |
ARM
|
CAS
WA - trip
|
| 2. |
6179832
|
[1] |
SPACER
|
CAS
|
| 3. |
413-624
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 4. |
496-11041
|
[10] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 5. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
61978
|
[1] |
KEY
|
CAS
1/4 X 2-1/2 GIB KEY
|
| 7. |
6524946
|
[1] |
WIPER ARM
|
CAS
ARM WA - door
|
| 8. |
434-616
|
[10] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 9. |
329-286
|
[10] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 10. |
433-828
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 11. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 12. |
230-4118
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HTLN GRB
|
| 13. |
858308
|
[1] |
SPRING
|
CAS
- extension
|
| 14. |
432-1632
|
[1] |
COTTER PIN,1/4" x 2"
|
CAS
Pin, Split (Cotter), 1/4" x 2" Superseded by part number: 88182
|
| 15. |
766485
|
[1] |
EYEBOLT,3/8" - 16 x 5", Full Thd
|
CAS
DRAWBOLT
|
| 16. |
700123432
|
[1] |
STOP
|
CAS
WA
|
| 17. |
425-106
|
[3] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 18. |
433-512
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 19. |
231-5145
|
[6] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 20. |
700112815
|
[2] |
SUPPORT
|
CAS
|
| 21. |
N5077
|
[2] |
FLANGED BEARING
|
CAS
BEARING ASSEMBLY - flanged
|
| 22. |
700137321
|
[1] |
DOOR
|
CAS
WA
|
| 23. |
121-237
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 24. |
700137346
|
[1] |
PIN
|
CAS
WA
|
| 25. |
6524870
|
[1] |
ROLLER,41.28mm OD x 19mm L
|
CAS
- clutch
|
| 26. |
100-1175
|
[2] |
SNAP RING,#75, Ext
|
CAS
Ring, Snap, #75, Ext Superseded by part number: 72186587, 129164
|
| 27. |
495-81070
|
[5] |
WASHER,1 1/32" x 1 1/2" x .120"
|
CAS
1 X 10 GAUGE NRMB Superseded by part number: 86624170
|
| 28. |
700137341
|
[1] |
ARM
|
CAS
WA
|
| 29. |
6525042
|
[1] |
ROLLER,41.28mm OD x 12.5mm L
|
CAS
- clutch
|
| 30. |
195-2103
|
[1] |
WASHER,1 1/16" x 1 1/2" x .065"
|
CAS
1 X 18 GAUGE NRMB
|
| 31. |
100-11100
|
[1] |
SNAP RING,#100, Ext
|
CAS
Ring, Snap, #100, Ext Superseded by part number: 25121
|
| 32. |
700720067
|
[1] |
ROD
|
CAS
END - female
|
| 33. |
425-158
|
[1] |
JAM NUT,Jam, 1/2"-20, G5
|
CAS
|
| 34. |
700137343
|
[1] |
ROD
|
CAS
|
| 35. |
7774151
|
[1] |
NUT
|
CAS
1/2-20 HJN LH Superseded by part number: 88722
|
| 36. |
700715897
|
[1] |
END
|
CAS
ROD END - female
|
| 37. |
113-242
|
[1] |
BOLT
|
CAS
3/8-16 X 1-1/4 FTC Superseded by part number: 88011
|
