| 1. |
413-512
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 2. |
232-5315
|
[14] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 3. |
700137228
|
[1] |
BRACKET
|
CAS
- stop
|
| 4. |
8027005
|
[1] |
PAD
|
CAS
- rubber
|
| 5. |
7883358
|
[8] |
SCREW,Hex Washer, 5/16" - 18 x 1 1/2"
|
CAS
5/16-18 X 1-1/2 HWHMS Superseded by part number: 163-56
|
| 6. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 7. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 8. |
329-286
|
[4] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 9. |
700137233
|
[1] |
LEVER
|
CAS
WA
|
| 10. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
5/8 NARROW PLAIN WASHER Superseded by part number: 87365
|
| 11. |
428-832
|
[1] |
BOLT,Hex, 1/2" - 20 x 2", Gr 8
|
CAS
1/2-20 X 2 C GR8 Superseded by part number: 87779103, 280564
|
| 12. |
495-21056
|
[3] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 13. |
700707867
|
[1] |
NUT
|
CAS
1/2-20 HFTLN GR/G Superseded by part number: 87033645
|
| 14. |
700137750
|
[1] |
SPACER
|
CAS
|
| 15. |
700720050
|
[1] |
CAM FOLLOWER
|
CAS
BEARING - cam follower
|
| 16. |
666624R91
|
[2] |
BALL BEARING,16.26mm ID x 40mm OD x 18mm W
|
IH
- cylindrical
|
| 17. |
100-21156
|
[1] |
SNAP RING,1.562", Int, #156
|
CAS
Ring, Snap, 1.562", Int, #156 Superseded by part number: 9635563
|
| 18. |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
5/8-11 X 2-3/4 C Superseded by part number: 88693
|
| 19. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 20. |
232-53110
|
[1] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 21. |
413-828
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| 22. |
231-5348
|
[3] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 23. |
700714987
|
[1] |
SPRING
|
CAS
- extension
|
| 24. |
700715897
|
[1] |
END
|
CAS
ROD END - female
|
| 25. |
7774151
|
[1] |
NUT
|
CAS
1/2-20 HJN LH Superseded by part number: 88722
|
| 26. |
700137229
|
[1] |
ROD
|
CAS
|
| 27. |
425-158
|
[1] |
JAM NUT,Jam, 1/2"-20, G5
|
CAS
|
| 28. |
700720067
|
[1] |
ROD
|
CAS
END - female
|
| 29. |
700137225
|
[1] |
ARM
|
CAS
WA
|
| 30. |
700706548
|
[1] |
HEX SOC SCREW
|
CAS
1/2-13 X 2-1/4 HSHCS SPL
|
| 31. |
6845507
|
[2] |
BRACKET
|
CAS
|
| 32. |
700119832
|
[3] |
HOUSING
|
IH
- bearing
|
| 33. |
6105159
|
[3] |
NYLON BEARING,1.75"
|
IH
BEARING - tine
|
| 34. |
413-432
|
[3] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
IH
Superseded by part number: 72187193, 87404
|
| 35. |
232-4114
|
[3] |
LOCK NUT,1/4"-20, GC
|
CAS
1/4-20 HTLN GRB Superseded by part number: 280129
|
| 36. |
700137319
|
[1] |
FINGER
|
CAS
WA
|
