凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (5-18) - PLUNGER CAM AND CRANK ARM BEARING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
178 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700715740
|
[2] |
SEAL
|
CAS
|
| 2. |
700720004
|
[2] |
RING
|
CAS
- retaining, internal Superseded by part number: 9706544
|
| 3. |
700715741
|
[1] |
SPHERICAL BEARING,65mm ID x 120mm OD x 31mm W
|
CAS
BEARING - roller, spherical
|
| 4. |
700137110
|
[1] |
HOUSING
|
CAS
- bearing
|
| 5. |
378814R1
|
[1] |
CAP
|
IH
- hub
|
| 6. |
700113171
|
[1] |
NUT
|
CAS
- stake
|
| 7. |
700706125
|
[1] |
WASHER,33.86mm ID x 55.19mm OD x 3.17mm Thk
|
CAS
- tongued
|
| 8. |
700706124
|
[1] |
BEARING ASSY,34.94mm ID x 65.11mm OD x 40.08mm W
|
CAS
BEARING ASSEMBLY
|
| 9. |
700113170
|
[1] |
ROLLER,90.13mm OD x 51mm L
|
CAS
- cam
|
| 10. |
700124026
|
[1] |
SHAFT
|
CAS
|
