| 1. |
700137215
|
[1] |
SCRAPER
|
CAS
WA - left Superseded by part number: 86632588, 87023124, 86521609, 700163300
|
| 2. |
700137217
|
[1] |
SCRAPER
|
CAS
WA - right Superseded by part number: 86521609, 86632588, 700163301, 87023124
|
| 3. |
433-512
|
[8] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 4. |
496-21034
|
[8] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 5. |
231-5145
|
[8] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 6. |
700137150
|
[1] |
PLUNGER
|
CAS
WA
|
| 7. |
700123184
|
[2] |
LARGE PLATE
|
CAS
PLATE
|
| 8. |
433-820
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 9. |
231-5348
|
[4] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 10. |
700713894
|
[12] |
BRUSH
|
CAS
|
| 11. |
7713829
|
[2] |
BEARING ASSY,19.56 mm ID x 63.75 mm OD
|
IH
PLUNGER BEARING Superseded by part number: 688282
|
| 12. |
232-5315
|
[24] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 13. |
413-516
|
[24] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 9635884, 72187198
|
| 14. |
700129690
|
[12] |
RETAINER
|
CAS
|
| 15. |
700137207
|
[1] |
PLATE ASSY.
|
CAS
PLATE WA - right
|
| 16. |
413-616
|
[15] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 17. |
492-11038
|
[23] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 18. |
496-11041
|
[23] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 19. |
700113187
|
[5] |
ANTI-WRAP PLATE
|
CAS
PLATE
|
| 20. |
700137204
|
[1] |
PLATE ASSY.
|
CAS
PLATE WA - left
|
| 21. |
492-11075
|
[2] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 22. |
425-1112
|
[2] |
NUT,3/4"-16, G5
|
CAS
3/4-16 H Superseded by part number: 80001689
|
| 23. |
700123193
|
[2] |
ANGLE
|
CAS
- side, center
|
| 24. |
700123192
|
[2] |
ANGLE
|
CAS
- side, lower
|
| 25. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 26. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 27. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 28. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 29. |
434-616
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 30. |
425-106
|
[8] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 31. |
61-46224
|
[14] |
HEX SOC SCREW,FLAT, 5/8" x 1-1/2"
|
CAS
5/8-11 X 1-1/2 HSFCHCS SPL
|
| 32. |
700113188
|
[7] |
KNIFE
|
CAS
|
| 33. |
700113189
|
[7] |
BAR
|
CAS
|
