凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (5-22) - PLUNGER CLEANER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
936 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700137213
|
[1] |
HALF BLADE
|
CAS
BLADE WA (Includes item 2)
|
| 2. |
740787
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 3. |
6232946
|
[4] |
BUSHING
|
CAS
Superseded by part number: 706232946
|
| 4. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 5. |
496-81010
|
[6] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 6. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 7. |
700122588
|
[2] |
ANGLE
|
CAS
|
| 8. |
700137144
|
[2] |
STRAP
|
CAS
|
| 9. |
6518302
|
[2] |
SPACER
|
CAS
|
| 10. |
433-632
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 2", G5 Superseded by part number: 280661
|
