凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (6-04) - TENSIONER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
338 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700137469
|
[1] |
ROD
|
CAS
WA
|
| 2. |
700714986
|
[6] |
SPRING
|
CAS
- extension
|
| 3. |
329-286
|
[17] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 4. |
432-1024
|
[1] |
COTTER PIN,5/32" x 1 1/2"
|
CAS
5/32" x 1 1/2" Superseded by part number: 72187233, 88350
|
| 5. |
495-21106
|
[1] |
WASHER,1"
|
CAS
1 HARDENED PLAIN WASHER Superseded by part number: 87374
|
| 6. |
231-5146
|
[6] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 7. |
6848832
|
[1] |
ANGLE
|
CAS
|
| 8. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 9. |
702400048
|
[6] |
ROD
|
CAS
Superseded by part number: 700602446
|
| 10. |
409-7612
|
[7] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HFSS Superseded by part number: 72187187, 255918
|
| 11. |
6845077
|
[6] |
TENSIONER
|
CAS
ASSEMBLY
|
| 12. |
700137477
|
[1] |
SUPPORT
|
CAS
STRAP WA
|
| 13. |
700137460
|
[1] |
SUPPORT
|
CAS
WA
|
