| 1. |
700710413
|
[24] |
BOLT,Round, 1/2" - 13 x 2 1/2", Grade 8, BLK
|
CAS
1/2-13 X 2-1/2 RHSNB GR8 NP
|
| 2. |
495-21056
|
[24] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 3. |
20835R1
|
[24] |
NUT,1/2"-13, G8
|
IH
1/2-13 H GR8 NP Superseded by part number: 9803187
|
| 4. |
700710414
|
[24] |
JAM NUT
|
CAS
1/2-13 HJN GR8 NP
|
| 5. |
413-1036
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 X 2-1/4 C Superseded by part number: 88556
|
| 6. |
232-53110
|
[1] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 7. |
700137451
|
[1] |
SUPPORT
|
CAS
WA - needle (Includes item 37)
|
| 8. |
866566
|
[6] |
FASTENER,#10 - 32 x 9/16"
|
CAS
(special)
|
| 9. |
700707700
|
[6] |
BALL BEARING,6.48 mm ID x 31.75 mm OD x 13.08 mm
|
CAS
BEARING Superseded by part number: 700737442
|
| 10. |
164-102
|
[6] |
HEX SOC SCREW,FLAT, #10 - 32 x 1/2"
|
CAS
#10-32 X 1/2 HSFCHCS (special)
|
| 11. |
700123233
|
[6] |
NEEDLE
|
CAS
ASSEMBLY (Includes items 8, 9 and 10) Superseded by part number: 700145329
|
| 12. |
121-226
|
[4] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 13. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 14. |
25-1316
|
[1] |
NUT,1"-14, G5
|
CAS
NUT, SLOTTED, 1"-14, G5 Superseded by part number: 86020752
|
| 15. |
52258
|
[3] |
BUSHING
|
CAS
1 X 14 GAUGE NRMB
|
| 16. |
495-81070
|
[3] |
WASHER,1 1/32" x 1 1/2" x .120"
|
CAS
1 X 10 GAUGE NRMB Superseded by part number: 86624170
|
| 17. |
495-81205
|
[3] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 14 GAUGE NRMB
|
| 18. |
52324
|
[3] |
BUSHING
|
CAS
1-1/4 X 10 GAUGE NRMB Superseded by part number: 052324
|
| 19. |
432-1640
|
[3] |
COTTER PIN,1/4" x 2 1/2"
|
CAS
Pin, Split (Cotter), 1/4" x 2 1/2" Superseded by part number: 80752
|
| 20. |
700137472
|
[1] |
ROD
|
CAS
WA - protection (Includes item 25)
|
| 21. |
425-1514
|
[1] |
JAM NUT,Jam, 7/8"-14, G5
|
CAS
7/8-14 HJN GR2 Superseded by part number: 86636806
|
| 22. |
6530604
|
[1] |
ROD
|
CAS
- adjust
|
| 23. |
700113098
|
[1] |
STRAP
|
CAS
WA - safety
|
| 24. |
700137476
|
[2] |
ROD
|
CAS
WA - connecting (Includes item 25) Superseded by part number: 700139762
|
| 25. |
D46620
|
[3] |
BEARING,31.76 mm ID x 50.81 mm OD x 23.81 mm
|
CAS
BUSHING Superseded by part number: 70668028
|
| 26. |
413-820
|
[8] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 27. |
231-5348
|
[8] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 28. |
667925R91
|
[1] |
ROLLER BEARING,0.628" ID x 2" OD x 15 mm
|
IH
- roller Superseded by part number: 47577176
|
| 29. |
52233
|
[2] |
BUSHING
|
CAS
5/8 X 14 GAUGE NRMB Superseded by part number: 51200381
|
| 30. |
700123220
|
[2] |
PIVOT
|
CAS
WA Superseded by part number: 700153515
|
| 31. |
740522
|
[2] |
WASHER
|
CAS
1-1/2 X 10 GAUGE WRMB
|
| 32. |
Q3497
|
[4] |
WASHER
|
IH
- quick rep
|
| 33. |
425-1412
|
[2] |
JAM NUT,Jam, 3/4"-10, G5
|
CAS
3/4-10 HJN GR2 Superseded by part number: 86632557
|
| 34. |
66332
|
[2] |
FLOOR
|
NNA
Superseded by part number: 066332
|
| 35. |
A35113
|
[2] |
PIN
|
CAS
3/4 X 2 CLEVIS PIN
|
| 36. |
19329R1
|
[2] |
LOCK PIN,5/32" x 1 1/2", Slotted
|
IH
Pin, 5/32" x 1 1/2", Slotted Superseded by part number: 70923740
|
| 37. |
700123261
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
