凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (6-30) - LUBE PUMP AND LINE ASSEMBLY, TWINE FINGER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
356 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51200288
|
[10] |
ELBOW
|
CAS
- male
|
| 2. |
L18337
|
[18] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 3. |
700123461
|
[1] |
WIRE HARNESS
|
CAS
HARNESS ASSEMBLY - left
|
| 4. |
700123362
|
[1] |
FLEXIBLE SHEATH
|
CAS
1/2 COVERING - protective (10 foot bulk)
|
| 5. |
700113359
|
[1] |
TUBE,0.125" OD, 3048 mm Length
|
CAS
TUBING - nylon (10 foot bulk)
|
| 6. |
700113360
|
[1] |
FLEXIBLE SHEATH
|
CAS
1/4 COVERING - protective (10 foot bulk)
|
| 7. |
700706279
|
[2] |
COUPLING, QUICK, FEM
|
CAS
COUPLER - snap on
|
| 8. |
700711751
|
[2] |
CLAMP
|
CAS
|
| 9. |
163-16
|
[7] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 3/4"
|
CAS
1/4-20 X 3/4 HWHMS
|
| 10. |
1703354
|
[7] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 11. |
751321
|
[5] |
CLAMP
|
CAS
Superseded by part number: 80272535
|
| 12. |
700122683
|
[1] |
WIRE HARNESS
|
CAS
HARNESS ASSEMBLY - right
|
| 13. |
700113353
|
[1] |
SUPPORT
|
CAS
|
| 14. |
700706539
|
[1] |
PLUG
|
CAS
- stop
|
| 15. |
700706540
|
[1] |
COPPER WASHER
|
CAS
GASKET
|
| 16. |
700706543
|
[1] |
3 WAY CONNECTION
|
CAS
STUD - tee
|
| 17. |
700706542
|
[1] |
3 WAY CONNECTION
|
CAS
NIPPLE - tee
|
| 18. |
700706541
|
[1] |
COPPER WASHER
|
CAS
GASKET
|
| 19. |
700113361
|
[1] |
SUPPORT
|
CAS
- pump
|
| 20. |
700706276
|
[1] |
SMALL PUMP
|
CAS
PUMP - multiluber
|
| 21. |
700706277
|
[12] |
TUBE NUT
|
CAS
- compression
|
