| 1-3. | VA3176182010 | [1] | INJECTION PUMP GENERAL ASSY ((N.D.K NO.) 190000-0510), FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES, (FOR M0 ONLY) | |
| 1-3. | VA3176182070 | [1] | PUMP INJECTION INJECTION PUMP GENERAL ASSY ((N.D.K NO.) 190000-0500), FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES (FOR M1,M2,M4 ONLY) | PUMP INJECTION INJECTION PUMP GENERAL ASSY ((N.D.K NO.) 190000-0500), FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES (FOR M1,M2,M4 ONLY) |
| 1-3. | VA3176182050 | [1] | INJECTION PUMP GENERAL ASSY ((N.D.K NO.) 190000-1790), FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES (FOR M3 ONLY) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY (31761—82100), FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES, SEE FIG 07-002 |
| 2. | VA3176183200 | [1] | GOVERNOR ASSY, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES, SEE FIG 07-003 (FOR M0 ONLY) | |
| 2. | VA3176182700 | [1] | GOVERNOR ASSY, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES, SEE FIG 07-003 (FOR M1,M2,M4 ONLY) | |
| 2. | VA3176183300 | [1] | GOVERNOR ASSY, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES, SEE FIG 07-003 (FOR M3ONLY) | |
| 3. | VA3176183030 | [1] | FEED PUMP | KOBFUEL FEED PUMP ASSY, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES, SEE FIG 07-004, Start Serial: 7909 Superseded by part number: VA0921001020 |
| 4. | VA3173620600 | [1] | PIPE PIPE, OIL, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES (FOR M0,M1,M2,M3 ONLY) | PIPE PIPE, OIL, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES (FOR M0,M1,M2,M3 ONLY) |
| 4. | VA3176181301 | [1] | PIPE, OIL | |
| 5. | VAMF477022 | [1] | CLIP (FOR M0,M1,M2,M3 ONLY) | |
| 5. | VAMH021107 | [1] | CLIP | |
| 5A. | VAME930208 | [1] | STAY (FOR M0,M1,M2,M3 ONLY), Start Serial: 7909 | |
| 6. | VAMF240023 | [1] | BOLT & WASHER ASSY BOLT W/WASHER 6X12 (FOR M0,M1,M2,M3 ONLY), Start Serial: 7909 | BOLT & WASHER ASSY BOLT W/WASHER 6X12 (FOR M0,M1,M2,M3 ONLY), Start Serial: 7909 |
| 6. | VAMF240049 | [1] | BOLT W/WASHER 8X12 | |
| 7. | VA3176183100 | [1] | LEVER, GOVERNOR INST. OF KN. 66, SEE FIG 07-003, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES (FOR M4 ONLY) | |
| 9-9A. | VAME006039 | [1] | FLANGE PLATE ASSY, Start Serial: 8001 | |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, FLANGE, (ME006013), Start Serial: 8001 |
| 9. | VA3136111401 | [1] | PLATE, FLANGE | |
| 9A. | VAME006031 | [1] | BAR, GUIDE, Start Serial: 8001 | |
| 10. | VAMF430122 | [4] | NUT | KOBNUT10 Superseded by part number: VAF230510000 |
| 10. | VAMF430006 | [1] | NUT | KOBNUT10 Superseded by part number: VAF230510000 |
| . . | VAMF450406 | [4] | WASHER | KOBWASHER, SPRING 10 |
| . . | VAMH005068 | [4] | WASHER | KOBWASHER, PLAIN |
| 11. | VA3136101300 | [1] | O-RING | KOBO-RING |
| 12. | VAMH035098 | [1] | ORING O-RING | ORING O-RING |
| 13. | VAMF243653 | [1] | BOLT W/WASHER 8X25, Serial Range: -7912 | |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONSPACER, -SEEFIG 05-007 (FOR M0,M1,M2,M3 ONLY), Start Serial: 7909 |
| 14. | VAMC401536 | [1] | SPACER, -SEEFIG 05-007 T=6 (FOR M4 ONLY) | |
| 15. | VAMF450007 | [1] | WASHER | KOBWASHER, PLAIN 12 (FOR M4 ONLY) Superseded by part number: 132624A1 |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONBOLT W/WASHER 12X30, -SEE FIG 05-007 (FOR M0,M1,M2,M3 ONLY), Start Serial: 7909 |
| 16. | VAMF300868 | [1] | BOLT | KOBBOLT W/WASHER 12X30, -SEE FIG 05-007 12X30 (FOR M0,M4 ONLY) |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONCONNECTOR, SEEFIG 01-005 KN. 54 |
