神钢零件查询(65R5C) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (07-002) - INJECTION PUMP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
964 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-53. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY, FF: SERVICE PARTS EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES ((N.D.K NO.) 090100-3020(31761-82100) |
| 1-2. | VA1901101381 | [1] | PUMP HOUSING KIT (N.D.K NO.) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING, PUMP |
| 2. | VA9490430010 | [3] | BOLT STUD | |
| 3. | VA0901500740 | [6] | PUMP ELEMENT C0MPLET PUMP ELEMENT SUB ASSY | PUMP ELEMENT C0MPLET PUMP ELEMENT SUB ASSY |
| 4. | VA0901400061 | [6] | DELIVERY SUB ASSY DELIVERY VALVE SUB ASSY | DELIVERY SUB ASSY DELIVERY VALVE SUB ASSY |
| 4. | VA0901370010 | [6] | GASKET, DELIVERY VALVE | |
| 6. | VA0901360040 | [6] | SPRING, DELIVERY VALVE | |
| 7. | VA0901310010 | [6] | HOLDER, DELIVERY VALVE | |
| 8. | VA0902120010 | [1] | RACK, CONTROL | |
| 9. | VA0902150010 | [1] | SCREW, RUCK GUIDE | |
| 10. | VA0901610160 | [6] | SLEEVE, CONTROL | |
| 11. | VA0901560010 | [6] | PINION, CONTROL | |
| 12. | VA0901570010 | [6] | SCREW, CLAMP | |
| 13. | VA0901630010 | [6] | SEAT UPPER SPRING | |
| 14. | VA0901640090 | [6] | SPRING, PLUNGER | |
| 15. | VA0901650020 | [6] | SEAT, LOWER SPRING | |
| 16-20. | VA0901700070 | [6] | TAPPET SUB ASSY | |
| 16. | VA0901760050 | [6] | PIN, ROLLER | |
| 17. | NSS | [6] | NOT SOLD SEPARAT | CONBODY TAPPET, (0901690070) |
| 18. | VA0901780030 | [6] | BUSHING, ROLLER | |
| 19. | VA0901810030 | [6] | ROLLER | |
| 20. | VA9490700111 | [6] | CIRCLIP | |
| 21. | VA0901890060 | [6] | PLUG, SCREW | |
| 22. | VA0901910151 | [1] | CAMSHAFT | |
| 24. | VA9491010120 | [2] | BEARING, ROLLER | |
| 25. | VA0901930020 | [2] | RING, ADJUST | |
| 25. | VA0902010300 | [1] | COVER, BEARING | |
| 27. | VA9491800060 | [1] | SCREW | KOBSCREW, FOLLOW |
| 29-32. | VA0902700940 | [1] | COVER SUB ASSY | |
| 29. | VA0902600130 | [1] | PLATE, COVER | |
| 30. | VA9490710190 | [2] | WASHER, SNAP | |
| 31. | VA0902430030 | [2] | PACKING WASHER | PACKING WASHER |
| 32. | VA0902760020 | [2] | SCREW, SET | |
| 36. | VA0902300031 | [1] | PLATE, LOCK | |
| 37. | VA0902490010 | [1] | SCREW, DRAIN, Serial Range: -8009 | |
| 38. | VA0902480010 | [1] | WASHER | KOBWASHER, Serial Range: -8009 |
| 39. | VA9491400060 | [1] | O-R1NG | |
| 39A. | VA0902060010 | [1] | GASKET | |
| 40. | VA0903610040 | [1] | BEARING, CENTER | |
| 41. | VA0903660021 | [2] | SCREW, GUIDE | |
| 42. | VA9490181030 | [2] | WASHER, PLATE | |
| 43-46. | VA0902400010 | [2] | BREATHER AIR BREATHER SUB ASSY | BREATHER AIR BREATHER SUB ASSY |
| 43. | VA0902410010 | [2] | PLUG | KOBWASHER, NIPPLE |
| 44. | VA0902420010 | [2] | NIPPLE, AIR BREATHER | |
| 45. | VA0902430030 | [2] | PACKING WASHER, NIPPLE | PACKING WASHER, NIPPLE |
| 46. | VA0902440010 | [2] | SCREW | KOBSCREW, AIR BREATHER |
| 47. | VA0902510010 | [2] | WASHER | KOBWASHER |
| 48. | VA9491400380 | [1] | O-RING O-RING | O-RING O-RING |
| 49. | VA0901940010 | [1] | SHIM T=0.10 | |
| 49. | VA0901940020 | [1] | SHIM T=0.12 | |
| 49. | VA0901940030 | [1] | SHIM T=0.14 | |
| 49. | VA0901940040 | [1] | SHIM T=0.16 | |
| 49. | VA0901940050 | [1] | SHIM T=0.18 | |
| 49. | VA0901940060 | [1] | SHIM T=0.50 | |
| 49. | VA0901940110 | [1] | SHIM T=0.30 | |
| 50. | VA9491800310 | [1] | JACK SCREW | KOBSCREW |
| 51. | VA0902220070 | [2] | WASHER | KOBWASHER Superseded by part number: VA0594601401 |
| 52. | VA9490471360 | [4] | BOLT W/WASHER | |
| 53. | VA0903110010 | [1] | SHIM | KOBT=0.6 |
| 53. | VA0903110020 | [1] | SHIM T=0.7 | |
| 53. | VA0903110030 | [1] | SHIM T=0.8 | |
| 53. | VA0903110040 | [1] | SHIM T=0.9 | |
| 53. | VA0903110050 | [1] | SHIM T=1.0 | |
| 53. | VA0903110060 | [1] | SHIM T=1.1 | |
| 53. | VA0903110070 | [1] | SHIM T=1.2 | |
| 53. | VA0903110080 | [1] | SHIM T=1.3 | |
| 53. | VA0903110090 | [1] | SHIM T=1 4 | |
| 53. | VA0903110100 | [1] | SHIM T=0.1 | |
| 53. | VA0903110110 | [1] | SHIM | KOBT=0.2 |
| 53. | VA0903110120 | [1] | SHIM | KOBT=0.3 |
| 53. | VA0903110130 | [1] | SHIM | KOBT=0.4 |
| 53. | VA0903110140 | [1] | SHIM | KOBT=0.5 |
| 53. | VA0903110150 | [1] | SHIM T=0.15 | |
| 54. | VA0900180081 | [1] | COVER CONTROL RACK | |
| 55. | VA9491300190 | [1] | KEY WOODRUFF | |
| 56. | VA0900120080 | [1] | NUT TIMER ROUND | |
| 57. | VA9490150500 | [1] | WASHER, SPRING | |
