神钢零件查询(65R5C) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (07-008) - FUEL FILTER (8011-) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
825 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-7. | VAME006064 | [1] | FILTER ASSY | KOBFUEL FILTER ASSY Superseded by part number: VAME229356 |
| 1. | VAME006065 | [1] | FILLER | KOBHEAD, FUEL FILTER |
| 2. | VAMH035069 | [4] | GASKET | KOBGASKET Superseded by part number: 133378A1 |
| 3. | VAMH037087 | [2] | BOLT | KOBBOLT, CONNECTOR |
| 4. | VAMH037084 | [1] | GLOW PLUG | KOBPLUG, AIR Superseded by part number: 77270641, VAME016894 |
| 5. | VAMH035067 | [1] | GASKET | KOBGASKET |
| 6-7. | VAME016823 | [1] | ELEMENT | KOBELEMENT ASSY Superseded by part number: 2451R124-2A |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONELEMENT, FUEL FILTER |
| 7. | VAME016825 | [1] | COVER DUST COVER, DUST | COVER DUST COVER, DUST |
| 8. | VA3089815600 | [1] | BOLT CONNECTOR (FOR M1 ONLY) FF:SERVICE PART EXCLUSIVELY USED FOR INDUSTRIAL MACHINERY ENGINES | |
| 9. | VAMH037237 | [1] | PLUG | KOBPLUG, TAPER PT 1/8 (FOR M1 ONLY) |
