神钢零件查询(65R5C) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (07-009 ) - FUEL FILTER (8010-) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
226 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-13. | VAME023834 | [1] | FILTER | KOBFUEL FILTER ASSY |
| 1. | VAME000018 | [1] | HEAD, FUEL FILTER | |
| 2. | VAME021349 | [1] | CASE, FUEL FILTER | |
| 3-5. | VAME023835 | [1] | ELEMENT FUEL FILTER ELEMENT KIT | ELEMENT FUEL FILTER ELEMENT KIT |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONELEMENT, FUEL FILTER (ME023833) |
| 4. | VAMH0350S2 | [1] | GASKET, CASE | |
| 5. | VAMH035056 | [1] | O-RING O-RING, CENTER BOLT | O-RING O-RING, CENTER BOLT |
| 6. | VAMH000139 | [1] | BOLT CENTER | |
| 7. | VAME000017 | [1] | SPRING, SAT | |
| S. | VAMF450007 | [1] | WASHER | KOBWASHER, PLAIN 12 Superseded by part number: 132624A1 |
| 10. | VAMH037087 | [2] | BOLT | KOBBOLT CONNECTOR |
| 11. | VAMH03S069 | [4] | GASKET | |
| 12. | VAMH037084 | [1] | GLOW PLUG | KOBPLUG, AIR Superseded by part number: 77270641, VAME016894 |
| 12A. | VAMH035067 | [2] | GASKET | KOBGASKET |
| 13. | VAMH037088 | [1] | DRAIN PLUG PLUG, DRAIN | DRAIN PLUG PLUG, DRAIN |
| 19. | VA3089815600 | [1] | BOLT CONNECTOR (INST.OF KN.10) (SERVICE PART EXCLUSIVELY FOR INDUSTRIAL MACHINERY ENGINES) (FOR M1 ONLY) | |
| 20. | VAMH037237 | [1] | PLUG | KOBPLUG, TAPER PT 1/8 (FOR M1 ONLY), Start Serial: 8010 |
| 20. | VAMH037135 | [1] | PLUG PLUG, TAPER PT 1/8 (FOR M1 ONLY) | PLUG PLUG, TAPER PT 1/8 (FOR M1 ONLY) |
