凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (02-24) - GEARBOX ASSEMBLY, S.N. CDH0139001 THRU CFH0139089 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700122641
|
[1] |
GEARBOX
|
CAS
ASSEMBLY COMPLETE
|
| 1. |
700706080
|
[1] |
GASKET
|
CAS
|
| 2. |
700113004
|
[1] |
FLANGE
|
CAS
WA - lower
|
| 3. |
700706033
|
[1] |
ROLLER BEARING,88.9 mm ID x 48.26 mm
|
CAS
BEARING - cone
|
| 4. |
700706089
|
[1] |
PINION
|
CAS
- intermediate
|
| 5. |
700707823
|
[1] |
SEALANT
|
CAS
Superseded by part number: MC37464
|
| 6. |
700112985
|
[6] |
LOCKING PLATE
|
CAS
TAB - lock Superseded by part number: 700730571
|
| 7. |
700706035
|
[1] |
ROLLER BEARING,63.5 mm ID x 43.764 mm
|
CAS
BEARING - cone
|
| 8. |
700708353
|
[31] |
SCREW
|
HFI
M12 X 1.75 X 40 C
|
| 9. |
8052136
|
[2] |
RING, SNAP
|
CAS
RING - retaining
|
| 10. |
S97820
|
[2] |
SPHERICAL BEARING,100mm ID x 180mm OD x 46mm W
|
CAS
BEARING - spherical
|
| 11. |
700706091
|
[1] |
GEAR
|
CAS
PINION - final
|
| 12. |
7052020
|
[1] |
RING
|
CAS
- retaining
|
| 13. |
700706090
|
[1] |
GEAR
|
CAS
- intermediate
|
| 14. |
700706048
|
[4] |
DOWEL,3/4" x 3/4"
|
CAS
- pin
|
| 15. |
ST807
|
[1] |
BEARING CUP,122.24mm OD x 36.51mm W
|
IH
BEARING - cup
|
| 16. |
700706074
|
[2.5] |
SHIM
|
CAS
0.08/.003
|
| 17. |
700706075
|
[1] |
SHIM
|
CAS
0.13/.005
|
| 18. |
700706076
|
[1] |
SHIM
|
CAS
0.25/.010
|
| 19. |
700706078
|
[2] |
SHIM
|
CAS
0.51/.020
|
| 20. |
700113014
|
[1] |
CAP
|
CAS
- right
|
| 21. |
700706046
|
[1] |
SEAL
|
CAS
|
| 22. |
614-10025
|
[15] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 23. |
892-10012
|
[27] |
LOCK WASHER,M12
|
CAS
|
| 24. |
825-1112
|
[27] |
NUT,M12, Cl 8
|
CAS
M12 X 1.75 H Superseded by part number: 9706685
|
| 25. |
700122642
|
[1] |
GEARBOX
|
CAS
ASSEMBLY
|
| 26. |
700112992
|
[1] |
SCRAPER BLADE
|
CAS
SCRAPER WA - right
|
| 27. |
700113018
|
[1] |
SPACER
|
CAS
- right
|
| 28. |
700706079
|
[2] |
GASKET
|
CAS
|
| 29. |
700113003
|
[2] |
FLANGE
|
CAS
WA - upper
|
| 30. |
700706092
|
[1] |
GEAR
|
CAS
- output
|
| 31. |
700112989
|
[1] |
SHAFT
|
CAS
- output
|
| 32. |
8799280
|
[1] |
FILTER
|
CAS
|
| 33. |
746354
|
[1] |
COUPLING
|
CAS
Superseded by part number: IH140813
|
| 34. |
746313
|
[1] |
NIPPLE, LUBE
|
CAS
NIPPLE
|
| 35. |
700112991
|
[1] |
SCRAPER BLADE
|
CAS
SCRAPER WA - left
|
| 36. |
700113017
|
[1] |
SPACER
|
CAS
- left
|
| 37. |
814-12060
|
[8] |
BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 9706693
|
