凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (02-26) - GEARBOX ASSEMBLY, (CON'T), S.N. CFH0139001 THRU CFH0139089 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (02-26) - GEARBOX ASSEMBLY, (CON'T), S.N. CFH0139001 THRU CFH0139089 Case Agriculture

广数供应链运营团队, 15 02月, 2025，浏览： 427 次

Pos.	Part No	Qty	Parts name	Comments
1.	700113012	[2]	COVER	CAS
2.	700706086	[2]	GASKET	CAS - front
3.	238-5270	[2]	O-RING,0.139" Thk x 8.984" ID, -270, Cl 5, 75 Duro	CAS Superseded by part number: 86625104
4.	700706041	[2]	SPHERICAL BEARING,150 mm ID x 225 mm OD x 56 mm	CAS BEARING - spherical
5.	700112993	[2]	SEAL	CAS CAP - output
6.	700708000	[2]	SEAL	CAS
7.	700708037	[2]	SNAP RING	CAS RING - retaining
8.	238-5257	[2]	O-RING,0.139" Thk x 5.859" ID, -257, Cl 5, 75 Duro	CAS Superseded by part number: 87016956
9.	700112988	[2]	SPACER	CAS - output
10.	700700502	[2]	SNAP RING	CAS RING - retaining
11.	700113015	[2]	COVER	CAS CAP - final pinion
12.	238-5262	[2]	O-RING,0.139" Thk x 6.984" ID, -262, Cl 5, 75 Duro	CAS Superseded by part number: 70924140
13.	628-12035	[12]	BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd	CAS BOLT, Hex, M12 x 35, 10.9, Full Thd
14.	700113013	[1]	CAP	CAS - left
15.	700706070	[2.5]	SHIM	CAS - left, inter 0.08/.003
16.	700706071	[1]	SHIM	CAS - left, inter 0.13/.005
17.	700706072	[1]	SHIM	CAS - left, inter 0.25/.010
18.	700706073	[2]	SHIM	CAS - left, inter 0.51/.020
19.	700706034	[2]	BEARING CUP,161.93mm OD x 38.1mm W	CAS BEARING - cup
20.	217-532	[1]	DRAIN PLUG,Sq Hd, 1 1/4"-11 1/2 NPTF	CAS PLUG, DRAIN, Sq Hd, 1 1/4"-11 1/2 NPTF
21.	700706142	[1]	THERMOSTAT	CAS ASSEMBLY
22.	700706030	[1]	ROLLER BEARING,76.2mm ID x 48.26mm W	CAS BEARING - cone
23.	700706032	[1]	WASHER	CAS - special
24.	700706065	[1]	NUT	CAS - stake
25.	700713657	[1]	GASKET	CAS - front, cap
26.	700124035	[1]	FLANGE COVER CAP	CAS CAP - front
27.	700706045	[2]	SEAL	CAS
28.	614-10030	[6]	BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd	IH Superseded by part number: 43140
29.	700708367	[6]	WASHER	HFI M10 L Superseded by part number: 140028
30.	700706082	[1]	GASKET	CAS - top
31.	700113011	[1]	COVER	CAS - top
32.	700706144	[1]	DIPSTICK	CAS GAUGE - oil
33.	700706088	[1]	BEVEL GEAR	CAS RING - gear, pinion
34.	700706027	[1]	ROLLER BEARING,84.138 mm ID x 46.038 mm	CAS BEARING - cone
35.	700706029	[1]	BEARING CUP	CAS BEARING - cup Superseded by part number: CASA140553
36.	700707769	[2]	SHIM	CAS - input, pinion 0.51/.020
37.	700706068	[2]	SHIM	CAS - input, pinion 0.08/.003
38.	700706067	[1]	SHIM	CAS - input, pinion 0.13/.005
39.	700706066	[1]	SHIM	CAS - input, pinion 0.25/.010
40.	614-8016	[22]	BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd	CAS C Hex, M8 x 16, 8.8 Superseded by part number: 16043224
41.	700708353	[3]	SCREW	HFI M12 X 1.75 X 40 C
42.	892-10012	[3]	LOCK WASHER,M12	CAS
43.	825-1112	[3]	NUT,M12, Cl 8	CAS M12 X 1.75 H Superseded by part number: 9706685
