神钢零件查询(65R5P) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (04-005) - MUFFLER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
880 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VA3089252000 | [1] | MUFFLER ASSY (FOR M0, M1 ONLY) | |
| 1. | VA3089252100 | [1] | MUFFLER (FOR M0, M1 ONLY) | |
| 2. | VA3089805200 | [2] | FLANGE (FOR M0, M1 ONLY) | |
| 4. | VAMF100116 | [6] | BOLT 12X40 (FOR M0, M1 ONLY) | |
| . . | VAMF430007 | [6] | NUT | KOBNUT 12 (FOR M0, M1 ONLY) |
| . . | VAMF450407 | [6] | WASHER WASHER, SPRING 12 (FOR M0, M1 ONLY) | WASHER WASHER, SPRING 12 (FOR M0, M1 ONLY) |
| 5. | VA3113206201 | [2] | GASKET GASKET (FOR M0, M1 ONLY) | GASKET GASKET (FOR M0, M1 ONLY) |
| 6-9. | VA3003233020 | [1] | FLEXIBLE PIPE ASSY (FOR M0 ONLY) | |
| 6. | VA3003233200 | [1] | PIPE, FLEXIBLE (FOR M0 ONLY) | |
| 7. | VAMF100089 | [8] | BOLT BOLT 10X35 (FOR M0 ONLY) | BOLT BOLT 10X35 (FOR M0 ONLY) |
| . . | VAMF430006 | [16] | NUT | KOBNUT 10 (FOR M0 ONLY) Superseded by part number: VAF230510000 |
| 8. | VA3089208100 | [2] | FLANGE (FOR M0 ONLY) | |
| 9. | VA3089208201 | [2] | GASKET (FOR M0 ONLY) | |
