凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (07-08) - SHIELDS ASSEMBLY, TOP AND FRONT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
290 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700150685
|
[1] |
SUPPORT
|
HFI
- pump (S.N. 4910-00481 and Later)
|
| 2. |
700114022
|
[2] |
CHANNEL
|
CAS
ANGLE
|
| 3. |
121-115
|
[26] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 4. |
231-5145
|
[26] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 5. |
700113952
|
[1] |
SHIELD
|
CAS
- front (S.N. CFH0139001 thru CFH0139499)
|
| . . |
700150690
|
[1] |
SHIELD
|
HFI
- front (S.N. CFH0139500 and Later)
|
| 6. |
700113953
|
[1] |
SHIELD
|
CAS
- top
|
| 7. |
413-816
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5
|
CAS
Superseded by part number: 87909, BN50282
|
| 8. |
230-4218
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HCLN
|
| 9. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 10. |
496-11041
|
[10] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 11. |
492-11038
|
[10] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 12. |
425-106
|
[10] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 13. |
700122886
|
[1] |
LID
|
CAS
WA Superseded by part number: 700121710
|
| 14. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 15. |
700113988
|
[1] |
CHANNEL
|
CAS
- top Superseded by part number: 700121708
|
| 16. |
700114020
|
[1] |
CHANNEL
|
HFI
- light, support
|
