| 1. |
700114044
|
[1] |
SHIELD
|
CAS
CAP WA - end, left Superseded by part number: 700121688
|
| 2. |
6849178
|
[1] |
WALL
|
CAS
SAFETY - walk (10 Foot)
|
| 3. |
6564512
|
[1] |
PLATFORM
|
CAS
PLATFORM ASSEMBLY (Includes Item 5)
|
| 4. |
433-612
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 5. |
231-5146
|
[8] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 6. |
700114054
|
[1] |
SHIELD
|
HFI
|
| 7. |
163-41
|
[3] |
SCREW,Sl Hex Wshr Hd, 5/16" - 18 x 1 1/4"
|
CAS
5/16-18 X 1-1/4 HWHMS
|
| 8. |
231-5145
|
[20] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 9. |
121-115
|
[11] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 10. |
700114040
|
[1] |
FRAME
|
CAS
WA - right Superseded by part number: 700121686
|
| 11. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 12. |
700114045
|
[1] |
SHIELD
|
CAS
CAP WA - end, right Superseded by part number: 700121690
|
| 13. |
700122881
|
[1] |
PIN
|
CAS
- hinge
|
| 14. |
121-108
|
[6] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 15. |
496-21034
|
[12] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 16. |
6564595
|
[2] |
STOP
|
CAS
- door
|
| 17. |
700114055
|
[1] |
DOOR
|
CAS
- top Superseded by part number: 700121692
|
| 18. |
700114039
|
[1] |
FRAME
|
CAS
WA - left Superseded by part number: 700121684
|
| 19. |
7894975
|
[8] |
CLIP
|
CAS
|
| 20. |
7758212
|
[8] |
SPRING
|
CAS
- compression
|
| 21. |
7894967
|
[8] |
HANDLE
|
CAS
|
