| 1. |
826271
|
[20] |
WASHER
|
CAS
|
| 2. |
29-1112
|
[20] |
NUT,3/4"-16, G8
|
CAS
3/4-16 H GR8 NP
|
| 3. |
7027469
|
[2] |
VALVE
|
CAS
STEM - valve
|
| 4. |
417194C1
|
[2] |
PLUG
|
IH
- valve stem
|
| 5. |
700708051
|
[2] |
RIM
|
CAS
WHEEL - 28L-26 Superseded by part number: 700714441
|
| 6. |
413-1072
|
[2] |
BOLT,Hex, 5/8" - 11 x 4-1/2", Gr 5
|
CAS
Superseded by part number: 280183
|
| 7. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 8. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 9. |
700112942
|
[2] |
SPINDLE
|
CAS
|
| 10. |
7744519
|
[2] |
SEAL
|
CAS
|
| 11. |
13331DB
|
[2] |
ROLLER BEARING,73.03mm ID x 36.17mm W
|
IH
- cone
|
| 12. |
826545
|
[20] |
BOLT
|
CAS
3/4-16 X 2-1/2 RIB NECK BOLT
|
| 13. |
13273D
|
[2] |
BEARING, CUP,2.8755" ID x 5.001" OD x 1.452"
|
IH
BEARING - cup Superseded by part number: 86013052
|
| 14. |
1968292C1
|
[2] |
BEARING
|
IH
- cup Superseded by part number: 510893
|
| 15. |
M53320
|
[2] |
BEARING ASSY
|
IH
BEARING - cone Superseded by part number: 510887
|
| 16. |
195-2146
|
[2] |
WASHER,1.56" ID x 3" OD x 0.13" Thk
|
CAS
1-1/2 NARROW PLAIN WASHER
|
| 17. |
25-1324
|
[2] |
SLOTTED NUT,1 1/2"-12, G5
|
CAS
1-1/2-12 SHN Superseded by part number: 86528705
|
| 18. |
700112940
|
[2] |
HUB
|
CAS
ASSEMBLY (Includes Items 12, 13, and 14)
|
| 19. |
432-2048
|
[2] |
COTTER PIN,5/16" x 3"
|
CAS
Pin, Split (Cotter), 5/16" x 3" Superseded by part number: 281072
|
| 20. |
826578
|
[2] |
HUB CAP
|
CAS
CAP - hub Superseded by part number: 28487101
|
| 21. |
413-512
|
[8] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 22. |
492-11031
|
[8] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
