| 1. |
413-1036
|
[6] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 X 2-1/4 C Superseded by part number: 88556
|
| 2. |
232-41110
|
[6] |
NUT,5/8"-11, GC
|
CAS
NUT, LOCK, 5/8"-11, GC Superseded by part number: 85700693
|
| 3. |
700109753
|
[4] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
BEARING ASSEMBLY (Includes Item 6)
|
| 4. |
433-824
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 5. |
329-288
|
[8] |
FLANGE NUT,Flg, 1/2"-13, G8
|
CAS
|
| 6. |
712158
|
[2] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 7. |
700113666
|
[1] |
SPACER
|
CAS
|
| 8. |
433-512
|
[14] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 9. |
231-5145
|
[18] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 10. |
52548
|
[6] |
SPECIAL WASHER
|
CAS
2 X 14 GAUGE NRMB
|
| 11. |
740407
|
[2] |
BRUSH, COMMUTATOR
|
CAS
2 X 10 GAUGE NRMB
|
| 12. |
433-612
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 13. |
231-5146
|
[16] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 14. |
434-616
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 15. |
700113663
|
[1] |
SPROCKET
|
CAS
WA 80C38 TOOTH
|
| 16. |
700113661
|
[1] |
NUT
|
CAS
1-5/8-12 NUT STAKE
|
| 17. |
Q81
|
[1] |
KEY,Gib, 3/8" Sq x 1 3/4"
|
IH
3/8 X 1-3/4 KEY - gib
|
| 18. |
700706097
|
[1] |
SPROCKET
|
CAS
60B15 TOOTH
|
| 19. |
700112826
|
[1] |
ANGLE
|
CAS
WA - right
|
| 20. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 21. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 22. |
329-286
|
[2] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 23. |
409-7512
|
[4] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 24. |
700112825
|
[1] |
ANGLE
|
CAS
WA - left
|
| 25. |
700134962
|
[1] |
PANEL
|
CAS
- front
|
| 26. |
6525471
|
[1] |
PANEL
|
CAS
WA
|
| 27. |
700112815
|
[2] |
SUPPORT
|
CAS
|
| 28. |
N5077
|
[2] |
FLANGED BEARING
|
CAS
FLANGE
|
| 29. |
616154R92
|
[6] |
BEARING, ROLLER, CYL,16 mm
|
IH
BEARING - cylindrical Superseded by part number: 84356151
|
| 30. |
700124036
|
[3] |
LINK CONROD
|
CAS
LINK ASSEMBLY (Includes Item 29)
|
| 31. |
700124038
|
[12] |
BUSHING,16.27mm ID x 34.92mm OD x 10mm L
|
CAS
- bearing
|
